44
Fig. 41 — TruVu DDC Controller Wiring Diagram
Port S2
Net+
Net
-
Shield
Rnet
Gnd
Rnet
+
Rnet
-
+
12V
End of
Net?
Yes
No
Up
Port S1
Net+
Net
-
Shield
Act Net
NC
Data
Gnd
AC/DC
Power
24V
1
O
N
UO-01
Common
Gnd
AO-02
AO-03
BO-02
Bus
BO-03
BO-04
BO-05
Bus
BO-06
BO-07
S1-Tx
S1-Rx
S2-Tx
S2-Rx
Prog
Net
Sys
Gnd
IN-05
24 Vdc
24 Vdc
IN-07
IN-06
Gnd
IN-08
Gnd
IN-01
IN-02
IN-03
IN-04
Gnd
Eth0 Eth1
10/100 Base-TX
Service
UO-01
Analog
Binary
(
Dry
Contact)
Comm
Carrier TruVu
i-Vu Ready
R
TM
DSC
TO
MODBUS
CARD
RATS
FACTORY INSTALLED COMPONENTS (OUTPUTS):
UO-1 - UNIVERSAL OUTPUT 1:
[ ] G1 - FAN ON (PSC & CT ECM)
[ ] ECM
- FAN MODULATION (CA ECM PWM)
[ ] VFD - FAN MODULATION (VFD 0-10VDC)
AO-2 - ANALOG OUTPUT 2:
[ ] MRV
- MODULATING REHEAT VALVE
BO-2 - BINARY OUTPUT 2:
[ ] Y1 - COMPRESSOR
BO-3 - BINARY OUTPUT 3:
[ ] O - REVERSING VALVE
BO-4 - BINARY OUTPUT 4:
[ ] Y2 - COMPRESSOR (TWO STAGE/SPEED)
[ ] WSE - WATER-SIDE ECONOMIZER VALVE (SINGLE STAGE)
[ ] W1 - AUX HEAT 1ST STAGE (SINGLE STAGE)
BO-5 - BINARY OUTPUT 5:
[ ] H - DEHUMIDIFICATION (HGRH)
[ ] W1 - AUX HEAT 1ST STAGE (SINGLE OR TWO
STAGE/SPEED)
BO-6 - BINARY OUTPUT 6:
[ ] G2 - FAN ON (CT ECM)
[ ] WSE
- WATER-SIDE ECONOMIZER VALVE (TWO STAGE)
[ ] W2 - AUX HEAT 2ND STAGE (TWO STAGE/SPEED)
BO-7 - BINARY OUTPUT 7:
[ ] G3 - FAN ON (CT ECM)
[ ] VFD - VFD ENABLE/DISABLE
STANDARD FACTORY INSTALLED COMPONENTS (INPUTS):
IN-2 - UNIVERSAL INPUT 2:
[ ] LWTS - LEAVING WATER TEMPERATURE SENSOR
IN-3 - UNIVERSAL INPUT 3:
[ ] EWTS - ENTERING WATER TEMPERATURE SENSOR
TERMINATION DETAIL
IN 1-2-3-6: TEMP SENSOR (77F/25C @ 10k-OHM)
IN 1-2-3-6
Gnd
TEMP SENSOR
Gnd
Rnet +
Rnet -
12V
GREEN
WHITE
BLACK
RED
ZS
SENSOR
TERMINATION DETAIL
Rnet
1
1
H SIGNAL IS USED ON REHEAT APPLICATIONS
2
3
TWO STAGE/SPEED UNITS: BO-4 IS ONLY
AVAILABLE FOR OUTPUT SIGNAL (Y2)
SINGLE STAGE/SPEED UNITS: BO-4 IS
AVAILABLE FOR WSE
4
5
OPTIONAL MODULATING REHEAT VALVE (MRV)
EQUIPMENT TOUCH DEVICE OR OPTIONAL
ZS COMBINATION WALL SENSOR CAPABLE
OF TEMPERATURE, HUMIDITY, AND CO2
READINGS.
TWO STAGE/SPEED UNITS: BO-6 IS AVAILABLE
FOR WSE OUTPUT SIGNAL
SINGLE STAGE/SPEED UNITS: BO-6 IS
AVAILABLE FOR FAN ON G2 OUTPUT SIGNAL
To BACnet
IP Network
USB
Service
Port
Dip Switch to
configure UO-1 as an
analog (CA ECM or
VFD) or binary (PSC
& CT ECM) output
Optional Smart
Source Water
Valve and/or
DCV Damper
Open for Optional Field
Inputs
TERMINATION DETAIL
IN-7-8: DRY CONTACT (N/C)
DPS
Gnd
IN 7-8
UO-01
Common
Gnd
AO-02
AO-03
BO-02
Bus
BO-03
BO-04
BO-05
Bus
BO-06
BO-07
Gnd
Rnet +
Rnet -
12V
WHITE
BLACK
EQUIPMENT
TOUCH
DEVICE
1
7
2
3
5
7
OPTIONAL FACTORY INSTALLED COMPONENTS (INPUTS):
IN-7 - UNIVERSAL INPUT 7:
[ ] DPS - DIFFERENTIAL PRESSURE SWITCH
OPTIONAL FIELD INSTALLED COMPONENTS (INPUTS):
IN-6 - UNIVERSAL INPUT 6:
[ ] SPT - SPACE TEMPERATURE SENSOR
IN-7 OR 8 - UNIVERSAL INPUT 7 OR 8:
[ ] EMSD - EMERGENCY SHUTDOWN
[ ] OCC - REMOTE OCCUPANCY
[ ] SCO - SECONDARY CONDENSATE OVERFLOW
[ ] FS - FLOW SWITCH
[ ] FM - WATER FLOW METER
6
IN-07 UTILIZED FOR OPTIONAL FACTORY
INSTALLED DIFFERENTIAL PRESSURE FLOW
SWITCH WHEN EQUIPPED
6
4
STANDARD FACTORY PROVIDED COMPONENTS (INPUTS):
IN-1 - UNIVERSAL INPUT 1:
[ ] SATS - SUPPLY AIR TEMPERATURE SENSOR
IN-6 - UNIVERSAL INPUT 6:
[ ] RATS
- RETURN AIR TEMPERATURE SENSOR
8733837662
