FOUNDATION Fieldbus Communication Introduction
Table 2 - Range Limits for Direct Connect Transmitters
Code
Range Limits — AP Range Limits — GP
D
0 and 1400 kPaa (0 and 200 psia) 0 and 1400 kPag (0 and 200 psig)
E
0 and 14 MPaa (0 and 2000 psia) 0 and 14 MPag (0 and 2000 psig)
F n/a
0 and 42 MPag (0 and 6000 psig)
12
Limits for Biplanar Transmitters
Table 3 - Span Limits for Biplanar Transmitters
Code
Span Limits
13
B
0.12 and 50 kPa (0.5 and 200 inH
2
O)
C
0.62 and 250 kPa (2.49 and 1000 inH
2
O)
D
26 and 2070 kPa (3.75 and 300 psi)
14
E
0.26 and 20.7 MPa (37.5 and 3000 psi)
14
F
1.1 and 34.5 MPa (165 and 5000 psi)
15 14
Table 4 - Range Limits for Biplanar Transmitters
Code
Range Limits — AP Range Limits — GP
B
5 and 50 kPaa (20 and 200 inH
2
Oa) -50 and +50 kPag (-200 and +200 inH
2
Og)
C
0 and 250 kPaa (0 and 1000 inH
2
Oa) -100 and +250 kPag (-401 and +1000 inH
2
Og)
D
0 and 2070 kPaa (0 and 300 psia)
14
-100 and +2100 kPag (-14.7 and +300 psig)
14
E
0 and 20.7 MPaa (0 and 3000 psia)
14
-0.1 and +21 MPag (-14.7 and +3000 psig)
14
F n/a
-0.1 and +35 MPag (-14.7 and +5000 psig)
14
Limits for DP Transmitters
Table 5 - Span Limits for DP Transmitters
Code
Span Limits
B
0.12 and 50 kPa; 0.5 and 200 inH
2
O; 1.2 and 500 mbar
C
0.62 and 250 kPa; 2.5 and 1000 inH
2
O; 6.2 and 2500 mbar
D
0.026 and 2.07 MPa; 3.75 and 300 psi; 0.26 and 20.7 bar
E
0.26 and 20.7 MPa; 37.5 and 3000 psi; 2.6 and 207 bar
14 MI 020-612
12. Direct connect GP transmitters with this Span Code can tolerate vacuum down to -0.1 MPa (-14.7 psi). However, to measure vacuum
accurately with a GP transmitter, a biplanar Structure Code is required.
13. Values listed are in absolute or gauge pressure units, as applicable.
14. Span limit, maximum working pressure, maximum overrange pressure, and maximum static pressure (d/p) are derated for optional IEC 61518
Construction and optional Bolting except for codes -D3, -D7, and -B2. Option -D1 is derated to 2320 psi. Options -D5 and -B1 are derated to
2175 psi. Options -D2, -D4, -D6, and -D8 are derated to 1500 psi. Option -B3 is derated to 2900 psi.
15. Available for gauge pressure transmitters only.
