1765274 08/2012 31

11. Network objects

b Analog inputs

Analog input object instance summary

The following table summarizes the analog input objects supported:

(2): Extended I/O option card terminals (VW3 A3 202).

b Analog output

Analog output object instance summary

The following table summarizes the analog output objects supported:

(2): Extended I/O option card terminals (VW3 A3 202).

11. 3. Control objects

b ATV61 binary values

ATV61 binary value object instance summary

The following table summarizes the binary value objects supported:

* : See chapter 8.4 for more details

ID Object name Description Units Access

Analog Input #0 ANALOG INPUT 1 Analog input 1 value % R

Analog Input #1 ANALOG INPUT 2 Analog input 2 value % R

Analog Input #2 ANALOG INPUT 3 Analog input 3 value (2) % R

Analog Input #3 ANALOG INPUT 4 Analog input 4 value (2) % R

Analog Input #4 ANALOG INPUT 5 Analog input 5 value % R

ID Object name Description Units Access

Analog Output #0 AO1 COMMAND Analog output value % C

Analog Output #1 AO2 COMMAND Analog output value (2) % C

Analog Output #2 AO3 COMMAND Analog output value (2) % C

ID Object name Description Active/Inactive

text

Access

Binary Value #0 RUN/STOP ACT Indicates the drive status. READY/RUNS R

Binary Value #1 FWD/REV ACT Indicates the motor rotation’s direction. FWD/REV R

Binary Value #2 FAULT ACT Indicates the drive’s fault status. FAULTED/NONE R

Binary Value #4 HAND/AUTO ACT Indicates if the drive is locally controller or not. HAND/AUTO R

Binary Value #7 DRIVE READY The VSD is ready and waits a start command. NOT READY/READY R

Binary Value #8 AT SETPOINT The VSD has reached the target speed. NO/REACHED R

Binary Value #10 RUN/STOP CMD Commands a drive start. START/STOP C

Binary Value #11 FWD/REV CMD Commands a motor direction’s change. FWD/REV C

Binary Value #14 FAULT RESET Resets faults RESET/NO C

Binary Value #15 MBOX READ Command to read parameter * READ/RESET C

Binary Value #16 MBOX WRITE Command to write parameter * WRITE/RESET C

Binary Value #18 C311CMD Controls C311 ATV61 internal bit OFF/ON C

Binary Value #19 C312CMD Controls C312 ATV61 internal bit OFF/ON C

Binary Value #20 C313CMD Controls C313 ATV61 internal bit OFF/ON C

Binary Value #21 C314CMD Controls C314 ATV61 internal bit OFF/ON C

Binary Value #22 C315CMD Controls C315 ATV61 internal bit OFF/ON C
