32 1765274 08/2012

11. Network object

b Analog values

The following collection of analog values are also accessible through the parameter access group.

Analog value object instance summary

The following table summarizes the analog value objects supported:

(1)Parameter Modbus internal address. Refer to "Communication parameter" user’s manual.

ID Object name Description (Code) Units Access

Analog value #0 OUTPUT SPEED Output speed rmp R

Analog value #1 OUTPUT FREQ Output frequency Hz R

Analog value #2 DC BUS VOLT DC bus voltage V R

Analog value #3 OUTPUT VOLT Motor voltage V R

Analog value #4 CURRENT Motor current A R

Analog value #5 TORQUE Motor torque % R

Analog value #6 POWER Motor power % R

Analog value #7 DRIVE TEMP Drive thermal state % R

Analog value #8 KWH (R) Energy counter (erasable) kWh R

Analog value #9 KWH (NR) Energy counter (not erasable) kWh R

Analog value #10 PRC PID FBCK PID regulator feedback % R

Analog value #11 PRC PID DEV PID regulator feedback % R

Analog value #14 RUN TIME (R) Operating time H R

Analog value #15 MOTOR TEMP Motor temperature % R

Analog value #16 INPUT REF 1 Velocity / frequency setpoint from BACnet % C

Analog value #18 LAST FLT Error code - R

Analog value #19 PREV FLT 1 Previous fault (occurred before LASTFLT) - R

Analog value #20 PREV FLT 2 Previous fault (occurred before PREVFLT1) - R

Analog value #21 AO 1 ACT Analog output 1 level % R

Analog value #22 AO 2 ACT Analog output 2 level % R

Analog value #23 ACCEL1 TIME Acceleration time S W

Analog value #24 DECEL1 TIME Deceleration time S W

Analog value #25 MBOX PARAM Parameter number (1) - W

Analog value #26 MBOX DATA Parameter value - W

Analog value #27 EXT PID STPT PID regulator setpoint via the bus % C

Analog value #28 COM SCAN OUT1 General purpose AV V Comm. Scan. - W

Analog value #29 COM SCAN OUT2 General purpose AV V Comm. Scan. - W

Analog value #30 COM SCAN OUT3 General purpose AV V Comm. Scan. - W

Analog value #31 COM SCAN OUT4 General purpose AV V Comm. Scan. - W

Analog value #32 COM SCAN OUT5 General purpose AV V Comm. Scan. - W

Analog value #33 COM SCAN OUT6 General purpose AV V Comm. Scan. - W

Analog value #34 COM SCAN OUT7 General purpose AV V Comm. Scan. - W

Analog value #35 COM SCAN OUT8 General purpose AV V Comm. Scan. - W

Analog value #36 COM SCAN IN1 General purpose AV X Comm. Scan. - R

Analog value #37 COM SCAN IN2 General purpose AV X Comm. Scan. - R

Analog value #38 COM SCAN IN3 General purpose AV X Comm. Scan. - R

Analog value #39 COM SCAN IN4 General purpose AV X Comm. Scan. - R

Analog value #40 COM SCAN IN5 General purpose AV X Comm. Scan. - R

Analog value #41 COM SCAN IN6 General purpose AV X Comm. Scan. - R

Analog value #42 COM SCAN IN7 General purpose AV X Comm. Scan. - R

Analog value #43 COM SCAN IN8 General purpose AV X Comm. Scan. - R
