11. Network objects

11. 1. List of type supported by ATV61

•Drive I/O.

• Control.

• Parameters access.

• Identification.

11. 2. Drive I/O

b Binary inputs

Binary input object instance summary

The following table summarizes the binary input object supported:

(1): Logic I/O option card terminals (VW3 A3 201).

(2): Extended I/O option card terminals (VW3 A3 202).

b Binary outputs

Binary output object instance summary

The following table summarizes the binary output object supported:

(1): Logic I/O option card terminals (VW3 A3 201).

(2): Extended I/O option card terminals (VW3 A3 202).

ID Object name Description Active/Inactive

text

Access

Binary input #0 RO 1 ACT Indicates status of relay R1 ON/OFF R

Binary input #1 RO 2 ACT Indicates status of relay R2 ON/OFF R

Binary input #2 RO 3 ACT Indicates status of relay R3 (1) ON/OFF R

Binary input #6 DI 1 ACT Value of LI1 ON/OFF R

Binary input #7 DI 2 ACT Value of LI2 ON/OFF R

Binary input #8 DI 3 ACT Value of LI3 ON/OFF R

Binary input #9 DI 4 ACT Value of LI3 ON/OFF R

Binary input #10 DI 5 ACT Value of LI5 ON/OFF R

Binary input #11 DI 6 ACT Value of LI6 ON/OFF R

Binary input #12 DI 7 ACT Value of LI7 (1) ON/OFF R

Binary input #13 DI 8 ACT Value of LI8 (1) ON/OFF R

Binary input #14 DI 9 ACT Value of LI9 (1) ON/OFF R

Binary input #15 DI 10 ACT Value of LI10 (1) ON/OFF R

Binary input #16 DI 11 ACT Value of LI11 (2) ON/OFF R

Binary input #17 DI 12 ACT Value of LI12 (2) ON/OFF R

Binary input #18 DI 13 ACT Value of LI13 (2) ON/OFF R

Binary input #19 DI 14 ACT Value of LI14 (2) ON/OFF R

Binary input #20 DI 15 ACT Indicates status of logic output (1) ON/OFF R

Binary input #21 DI 16 ACT Indicates status of logic output (1) ON/OFF R

ID Object name Description Active/Inactive

text

Access

Binary Output #0 RO1 CMD R1 relay out accessible if not assigned ON/OFF C

Binary Output #1 RO2 CMD R2 relay out accessible if not assigned ON/OFF C

Binary Output 2 RO3 CMD R3 relay out accessible if not assigned (1) ON/OFF C

Binary Output #3 RO4 CMD R4 relay out accessible if not assigned (2) -/- C

Binary Output #4 RO5 CMD R5 relay out accessible if not assigned -/- C

Binary Output #5 RO6 CMD R6 relay out accessible if not assigned -/- C

Binary Output #6 RO7 CMD Logic output accessible if not assigned (1) ON/OFF C

Binary Output #7 RO8 CMD Logic output accessible if not assigned (1) ON/OFF C
