Table 26 — 50WD018 Typical Unit Operating Pressures and Temperatures
ENTER FLUID
TEMP
(°F)
WATER
FLOW
(gpm/ton)
COOLING HEATING
Suction
Pressure
(psig)
Discharge
Pressure
(psig)
Water Temp
Rise
(°F)
Air Temp
Drop
(°F)
Suction
Pressure
(psig)
Discharge
Pressure
(psig)
Water Temp
Rise
(°F)
Air Temp
Drop
(°F)
30
3 — — — — 57-67 250-270 6-7 18-22
5 — — — — 63-73 256-276 4-5 20-24
40
3 — — — — 70-80 264-284 7-8 21-25
5 — — — — 77-87 271-291 4-5 23-27
50
3 111-129 204-224 15-18 22-26 84-94 278-298 8-9 24-28
5 109-127 186-206 9-12 22-26 93-103 287-307 5-6 26-30
60
3 113-131 235-255 14-17 22-26 99-109 293-313 10-11 28-32
5 111-129 217-237 8-11 22-26 110-120 304-324 6-7 30-34
70
3 115-133 269-289 14-17 21-25 116-126 310-330 11-12 31-35
5 113-131 251-271 8-11 22-26 129-139 323-343 7-8 33-37
80
3 116-134 307-327 13-16 21-25 135-145 329-349 12-13 35-39
5 116-134 289-309 8-11 21-25 150-160 344-364 8-9 37-41
90
3 119-137 348-368 13-16 21-25 155-165 349-369 13-14 38-42
5 118-136 331-351 7-10 21-25 — — — —
100
3 121-139 393-413 12-15 20-24 — — — —
5 120-138 377-397 7-10 20-24 — — — —
Table 27 — 50WD024 Typical Unit Operating Pressures and Temperatures
ENTER FLUID
TEMP
(°F)
WATER
FLOW
(gpm/ton)
COOLING HEATING
Suction
Pressure
(psig)
Discharge
Pressure
(psig)
Water Temp
Rise
(°F)
Air Temp
Drop
(°F)
Suction
Pressure
(psig)
Discharge
Pressure
(psig)
Water Temp
Rise
(°F)
Air Temp
Drop
(°F)
30
3 — — — — 60-70 260-280 8-9 19-23
6 — — — — 67-77 267-287 4-5 21-25
40
3 108-125 188-206 19-22 21-25 73-83 274-294 10-11 22-26
6 106-123 160-178 9-12 21-25 82-92 283-303 5-6 24-28
50
3 109-126 215-233 19-22 21-25 87-97 289-309 12-13 25-29
6 108-125 187-205 9-12 21-25 98-108 300-320 6-7 27-31
60
3 111-128 245-263 18-21 21-25 102-112 305-325 13-14 28-32
6 109-126 217-235 9-12 21-25 115-125 319-339 7-8 31-35
70
3 112-129 279-297 18-21 20-24 119-129 323-343 15-16 32-36
6 111-128 250-268 9-12 21-25 135-145 340-360 8-9 35-39
80
3 114-131 315-333 17-20 20-24 137-147 342-362 17-18 35-39
6 113-130 288-306 8-11 20-24 157-167 364-384 9-10 39-43
90
3 116-133 354-372 17-20 19-23 164-174 371-391 19-20 40-44
6 115-132 330-348 8-11 20-24 — — — —
100
3 118-135 397-415 16-19 19-23 — — — —
6 117-134 376-394 8-11 19-23 — — — —
