Table 24 — 50WD012 Typical Unit Operating Pressures and Temperatures
ENTER FLUID
TEMP
(°F)
WATER
FLOW
(gpm/ton)
COOLING HEATING
Suction
Pressure
(psig)
Discharge
Pressure
(psig)
Water
Temp Rise
(°F)
Air Temp
Drop
(°F)
Suction
Pressure
(psig)
Discharge
Pressure
(psig)
Water Temp
Rise
(°F)
Air Temp
Drop
(°F)
30
2 — — — — 61-77 230-289 6-7 19-22
3 — — — — 64-81 233-294 4-5 20-23
40
2 109-135 151-193 14-18 22-26 74-93 242-304 7-8 22-26
3 109-134 141-180 10-11 22-27 78-98 246-310 5-6 23-27
50
2 109-137 175-224 14-18 22-25 81-117 256-321 9-10 25-29
3 109-136 164-210 10-11 22-26 86-124 262-328 6-7 27-31
60
2 110-139 201-257 13-18 22-26 104-128 271-339 10-12 28-33
3 110-138 191-244 9-11 22-26 111-137 278-347 7-8 29-35
70
2 112-142 231-294 13-17 22-25 121-149 287-358 11-13 31-37
3 112-140 221-281 9-12 21-25 130-158 295-368 7-9 33-39
80
2 113-144 263-334 12-17 21-25 140-170 306-380 12-14 35-41
3 113-143 254-321 8-11 21-25 151-182 316-392 8-10 37-44
90
2 115-147 299-379 12-16 21-24 — — — —
3 115-146 291-367 8-11 20-24 — — — —
100
2 116-149 338-428 12-15 20-24 — — — —
3 117-148 333-417 8-11 20-24 — — — —
Table 25 — 50WD015 Typical Unit Operating Pressures and Temperatures
ENTER FLUID
TEMP
(°F)
WATER
FLOW (gpm/
ton)
COOLING HEATING
Suction
Pressure
(psig)
Discharge
Pressure
(psig)
Water Temp
Rise (°F)
Air Temp
Drop
(°F)
Suction
Pressure
(psig)
Discharge
Pressure
(psig)
Water Temp
Rise
(°F)
Air Temp
Drop
(°F)
30
2.5
————
60-76 240-295 6-7 20-22
3.8
————
63-80 244-299 4-5 20-23
40
2.5 106-133 156-197 13-19 22-26 72-91 253-310 7-8 22-25
3.8 106-132 145-183 9-12 22-26 77-97 257-316 5-5 23-26
50
2.5 106-135 180-227 13-19 21-25 79-116 267-327 9-10 26-29
3.8 106-134 169-213 9-12 21-26 84-122 273-334 6-7 26-30
60
2.5 107-137 207-261 13-18 21-25 101-126 283-345 10-11 28-32
3.8 107-136 196-247 9-12 21-25 109-135 290-354 7-8 30-34
70
2.5 109-140 237-298 13-17 21-25 118-146 300-366 11-12 32-36
3.8 109-139 226-284 8-11 21-25 127-156 310-377 8-9 33-38
80
2.5 110-143 270-338 12-17 21-24 138-168 320-388 13-14 35-40
3.8 110-141 260-325 8-11 20-24 148-180 331-401 9-10 37-43
90
2.5 112-145 306-383 12-16 20-24 158-191 342-413 14-16 39-44
3.8 112-144 298-371 8-10 20-24
—— — —
100
2.5 113-147 346-434 11-16 20-23
—— — —
3.8 114-147 339-421 8-9 19-23
—— — —
