20
Table 7 — First Data Plate for Units with Electric Heater (EH) Option — Compressor Power Connection
a,b
50WD UNIT SIZE
VOLTAGE/ Hz /
PHASE
VOLTAGE
MIN/MAX
COMPRESSOR
FLA MCA MOP
Qty RLA LRA
018 208-230/1/60 197/253 1 7.4 39 7.4 9.3 15
024 208-230/1/60 197/253 1 10.3 62 10.3 12.8 20
030 208-230/1/60 197/253 1 14.6 82 14.6 18.2 30
036 208-230/1/60 197/253 1 14.6 90 14.6 18.2 30
042 208-230/1/60 197/253 1 18.2 106 18.2 22.8 40
048 208-230/1/60 197/253 1 18.3 138 18.3 22.9 40
060 208-230/1/60 197/253 1 25.2 147.3 25.2 31.5 50
070 208-230/1/60 197/253 1 28.0 166 28.0 35.0 60
NOTE(S):
a. Units with Factory Installed Electric Heat option will have two separate data plates for each electrical circuit.
b. Electric heat is not available for horizontal-straight through airflow configuration.
LEGEND
EH — Electric Heat
FLA — Full Load Amps
LRA — Locked Rotor Amp
RLA — Rated Load Amps
MCA — Minimum Circuit Amps
MOP — Maximum Overcurrent Protection
Table 8 — Second Data Plate for Units with 5 kW Electric Heater (EH) Option and
Constant Airflow ECM Motor
a,b
NOTE(S):
a. Units with Factory Installed Electric Heat option will have two separate data plates for each electrical circuit.
b. Electric heat is not available for horizontal-straight through airflow configuration.
50WD UNIT SIZE
VOLTAGE/
Hz / PHASE
VOLTAGE
MIN/MAX
BLOWER MOTOR
5 kW ELECTRIC HEATER
Heater Element 2nd Data Plate Values
Watts Amps MCA MOP
FLA Hp 208-v 240-v 208-v 240-v 208-v 240-v 208-v 240-v
018 208-230/1/60 197/253 4.4 0.33 3.6 k 4.8 k 17.3 20.0 27.2 30.5 25 30
024 208-230/1/60 197/253 4.4 0.33 3.6 k 4.8 k 17.3 20.0 27.2 30.5 25 30
030 208-230/1/60 197/253 5.0 0.50 3.6 k 4.8 k 17.3 20.0 27.9 31.3 25 30
036 208-230/1/60 197/253 8.4 0.75 3.6 k 4.8 k 17.3 20.0 32.2 35.5 30 35
042 208-230/1/60 197/253 8.4 0.75 3.6 k 4.8 k 17.3 20.0 32.2 35.5 30 35
048 208-230/1/60 197/253 8.4 0.75 3.6 k 4.8 k 17.3 20.0 32.2 35.5 30 35
060 208-230/1/60 197/253 9.1 1.0 3.6 k 4.8 k 17.3 20.0 33.0 36.4 30 35
070 208-230/1/60 197/253 9.1 1.0 3.6 k 4.8 k 17.3 20.0 33.0 36.4 30 35
LEGEND
EH — Electric Heat
FLA — Full Load Amps
Hp — Horsepower
LRA — Locked Rotor Amp
RLA — Rated Load Amps
MCA — Minimum Circuit Amps
MOP — Maximum Overcurrent Protection
