19
Table 5 — 50WD without Electric Heat — Constant Torque ECM Blower Motor Electrical Data
UNIT SIZE
VOLTAGE / Hz /
PHASE
VOLTAGE
MIN/MAX
COMPRESSOR BLOWER MOTOR
TOTAL
UNIT FLA
MCA MOCP
Quantity RLA LRA FLA Hp
007
208-230/1/60 197/253 1 2.7 17.0 2.3 0.25 5.0 5.7 15.0
265/1/60 238/292 1 2.3 12.0 2.3 0.25 4.6 5.1 15.0
009
208-230/1/60 197/253 1 3.3 20.0 2.3 0.25 5.6 6.4 15.0
265/1/60 238/292 1 2.8 15.0 2.3 0.25 5.1 5.7 15.0
012
208-230/1/60 197/253 1 4.7 27.0 2.3 0.25 7.0 8.2 15.0
265/1/60 238/292 1 3.7 23.0 2.3 0.25 6.0 6.9 15.0
LEGEND
FLA — Full Load Amps
Hp — Horsepower
LRA — Locked Rotor Amp
RLA — Rated Load Amps
MCA — Minimum Circuit Amp
MOCP — Maximum Overcurrent Protection
Table 6 — 50WD without Electric Heat — Constant Airflow ECM Blower Motor Electrical Data
a
NOTE(S):
a. 460-v units with Constant Airflow ECM blower motors require a neutral wire (4 wires).
UNIT SIZE
VOLTAGE / HZ /
PHASE
VOLTAGE
MIN/MAX
COMPRESSOR BLOWER MOTOR
TOTAL
UNIT FLA
MCA MOCP
Quantity RLA LRA FLA Hp
015
208-230/1/60 197/253 1 5.8 32.0 4.4 0.33 10.2 11.7 15.0
265/1/60 238/292 1 4.7 28 4.7 0.33 9.4 10.6 15.0
018
208-230/1/60 197/253 1 7.4 39 4.4 0.33 11.8 13.7 20.0
265/1/60 238/292 1 7.6 31 4.7 0.33 12.3 14.2 20.0
024
208-230/1/60 197/253 1 10.3 62 4.4 0.33 14.7 17.2 25.0
265/1/60 238/292 1 7.8 52 4.7 0.33 12.5 14.5 20.0
208-230/3/60 197/253 1 6.3 56 4.4 0.33 10.7 12.3 15.0
460/3/60 414/506 1 3.8 29.0 4.7 0.33 8.5 9.7 15.0
030
208-230/1/60 197/253 1 14.6 82 5.0 0.50 19.6 23.2 35.0
265/1/60 238/292 1 8.3 72.0 5.0 0.50 13.3 15.4 20.0
208-230/3/60 197/253 1 7.9 — 5.0 0.50 12.9 14.9 20.0
460/3/60 414/506 1 4.8 39.0 5.0 0.50 9.8 11.1 15.0
036
208-230/1/60 197/253 1 14.6 90 8.4 0.75 23.0 26.6 40.0
265/1/60 238/292 1 12.6 79.0 7.5 0.75 20.1 23.2 35.0
208-230/3/60 197/253 1 9.9 82 8.4 0.75 18.3 20.7 30.0
460/3/60 414/506 1 4.8 44.3 7.5 0.75 12.3 14.2 20.0
042
208-230/1/60 197/253 1 18.2 106 8.4 0.75 26.6 31.2 45.0
208-230/3/60 197/253 1 11.5 114 8.4 0.75 19.9 22.7 30.0
460/3/60 414/506 1 6.5 56 7.5 0.75 14.0 15.8 20.0
048
208-230/1/60 197/253 1 18.3 138 8.4 0.75 26.7 31.3 45.0
208-230/3/60 197/253 1 11.9 112 8.4 0.75 20.3 23.3 35.0
460/3/60 414/506 1 6.8 61.8 7.5 0.75 14.3 16.2 20.0
060
208-230/1/60 197/253 1 25.2 147.3 9.1 1.0 34.3 40.6 60.0
208-230/3/60 197/253 1 13.8 161 9.1 1.0 22.9 26.3 40.0
460/3/60 414/506 1 6.9 58 9.1 1.0 16.0 18.2 25.0
070
208-230/1/60 197/253 1 28.0 166 9.1 1.0 37.1 44.1 70.0
208-230/3/60 197/253 1 18.9 162.3 9.1 1.0 28.0 32.7 50.0
460/3/60 414/506 1 9.1 70.8 9.1 1.0 18.2 20.5 25.0
LEGEND
Hp — Horsepower
FLA — Full Load Amps
LRA — Locked Rotor Amp
RLA — Rated Load Amps
MCA — Minimum Circuit Amp
MOCP — Maximum Overcurrent Protection
