25
14. Select EXIT to return to the listing of parameters.
15. Select Parameter 30.14 and verify it equals the maximum
VFD output frequency.
16. If values are equal, then go to Step 19.
17. If values are not equal, select EDIT, press the UP/DOWN
buttons to match the required value.
18. Select SAVE to store the modified value.
19. Select EXIT to return to the listing of parameters.
20. Select EXIT to return to the main menu.
21. Press the HAND button and verify that the drive operates at
8
Hz.
22. Press Up arrow to increase speed and Down arrow to
decrease speed.
23. Press the Off button and verify that the fan stops.
24. Press the Auto button to operate the drive from the Energy
Management System (EMS) interface. Verify that all VFD
interface functions are working (start/stop, speed controls,
fire/smoke, shutdown, etc.) between the VFD and the EMS.
25. Refer to Table 7 for additional VFD information.
Table 7 — ACH580 - VFD Data
39L MOTOR
HP
ABB PART
MAX.
CONTINUOUS
FUSE AMPS
MCCB RATED
AMPS
PROGRAMMED SETTINGS
NO. ACH580-1 OUTPUT AMPS
OVERLOAD TRIP AMPS
4 POLE / 2 POLE
MAX. OUTPUT AMPS
4 POLE / 2 POLE
(208-230 VOLT / 3 PHASE / 60 HZ (PROGRAMMED TO OPERATE AT 208 VOLTS)
1/2 04A6-2 4.6 10 15 1.8/ 1.7 3.0/ 2.2
3/4 04A6-2 4.6 10 15 2.6/ 2.5 3.2/ 3.0
1 04A6-2 4.6 10 15 3.5/ 3.2 3.8/ 3.8
1-1/2 06A6-2 6.6 10 15 5.2/ 4.2 5.8/ 5.8
2 07A5-2 7.5 10 15 6.7/ 5.9 7.2/ 7.0
3 10A6-2 10.6 15 15 9.0/ 8.5 10.0/ 9.5
5 017A-2 16.7 25 25 14.5/ 13.6 16.7/ 16.0
7-1/2 024A-2 24.2 30 30 21.4/ 20.7 24.0/ 23.0
10 031A-2 30.8 40 40 27.4/ 27.4 30.8/ 30.0
15 046A-2 46.2 60 60 40.5/ 40.5 46.2/ 43.0
20 059A-2 59.4 80 80 53.0/ 52.2 59.4/ 57.0
25 075A-2 74.8 100 100 67.0/ 66.0 74.0/ 71.0
30 088A-2 88 110 110 82.0/ 78.0 85.0/ 82.0
40 114A-2 114 150 150 92.0/107.0 114.0/110.0
(208-230 VOLT / 3 PHASE / 60 HZ (PROGRAMMED TO OPERATE AT 230 VOLTS)
50 143A-2 143 200 200 125.0/130.0 142.0/130.0
60 169A-2 169 250 250 154.0/135.0 172.0/145.0
75 211A-2 211 300 300 186.0/166.0 221.0/172.0
100 273A-2 273 350 350 186.0/166.0 221.0/172.0
(460 VOLT / 3 PHASE / 60 HZ (PROGRAMMED TO OPERATE AT 460 VOLTS)
1/2 02A1-4 2.1 10 15 0.9/ 1.0 1.5/ 1.2
3/4 02A1-4 2.1 10 15 1.3/ 1.2 1.7/ 1.5
1 02A1-4 2.1 10 15 1.6/ 1.5 1.9/ 1.7
1-1/2 03A0-4 3 10 15 2.2/ 2.0 2.8/ 2.3
2 03A5-4 3.5 10 15 2.7/ 2.7 3.0/ 3.0
3 04A8-4 4.8 10 15 4.0/ 3.8 4.5/ 4.2
5 07A6-4 7.6 10 15 6.2/ 6.0 6.9/ 6.5
7-1/2 012A-4 11.9 15 15 9.0/ 8.8 10.0/ 9.5
10 014A-4 14.4 20 20 12.0/ 11.6 13.6/ 12.8
15 023A-4 23 30 30 17.6/ 16.5 19.3/ 19.0
20 027A-4 27 40 40 23.0/ 23.0 25.0/ 25.0
25 034A-4 34 40 40 29.0/ 28.0 31.0/ 30.0
30 044A-4 44 50 50 34.5/ 34.0 38.0/ 38.0
40 052A-4 52 80 80 46.0/ 44.0 48.0/ 50.0
50 065A-4 65 90 90 58.0/ 55.0 60.0/ 60.0
60 077A-4 77 100 100 73.0/ 68.0 77.0/ 72.0
75 096A-4 96 125 125 90.0/ 85.0 94.0/ 90.0
100 124A-4 124 175 175 118.0/110.0 124.0/114.0
125 156A-4 156 200 200 141.0/139.0 147.0/147.0
150 180A-4 180 250 250 171.0/171.0 177.0/177.0
(200-230 VOLT / 3 PHASE / 50 HZ (PROGRAMMED TO OPERATE AT 200 VOLTS)
1 04A6-2 4.6 10 15 3.3/ 3.3 3.9/ 3.9
1-1/2 06A6-2 6.6 10 15 4.9/ 4.9 5.8/ 5.8
2 07A5-2 7.5 10 15 6.3/ 6.3 7.1/ 7.1
3
10A6-2 10.6 15 15 8.7/ 8.7 10.0/ 10.0
4 017A-2 16.7 25 25 14.0/ 14.0 16.7/ 16.7
7-1/2 024A-2 24.2 30 30 21.2/ 20.2 24.2/ 24.2
