16
Table 3 — Additional Component Data
a
39L UNIT SIZE 03 06 08 10 12 15 18 21 25
TYPICAL DRY COIL WEIGHTS (lb)
Large Face Area Cooling Coils,
1/2 in. OD (Chilled Water & DX)
b
4-Row 56 84 98 109 137 178 198 251 280
6-Row 63 95 123 138 174 234 270 327 363
Small Face Area Cooling Coils,
1/2 in. OD (Chilled Water & DX)
b
4-Row 45 72 91 105 133 161 182 211 238
6-Row 53 85 113 129 162 197 225 270 307
8-Row 61 92 129 143 189 228 263 324 377
Hot Water Coils, 1/2 in. OD
b
1-Row 19 34 38 48 58 62 77 86 95
2-Row 28 43 51 61 76 89 104 117 130
Steam Coils, 1-row, 1-in. OD
6-FPI 50 70 85 95 110 135 150 180 215
9-FPI 55 80 100 115 125 155 175 214 256
12-FPI 60 85 115 130 145 180 205 248 297
FAN
Wheel Diameter (in.) 9-1/2 12-5/8 12-5/8 15 15 18-1/8 20 20 25
Wheel Width (in.) 7-1/8 9-1/2 11-1/8 11-1/8 15 15 13-1/2 18 15
Shaft Diameter (in.) 3/4 1-3/16 1-3/16 1-3/16 1-3/16 1-7/16 1-7/16 1-7/16 1-11/16
Maximum Fan rpm 2500 2000 2000 1600 1600 1400 1300 1100 1000
OPERATING CHARGE (Approximate),
DIRECT EXPANSION COIL
Refrigerant R-410A or R-22 (lb)
4-Row Coil 1-2 2-3 3-4 4-5 4-5 5-6 6-7 6-8 6-9
6-Row Coil 1-2 2-4 5-6 5-6 6-8 8-10 9-11 11-13 11-16
8-Row Coil 2-3 3-5 5-6 5-7 7-9 10-12 12-14 13-19 16-24
COIL VOLUME (gal. water)
Chilled Water, 1/2 in. OD Tube,
Large Face Area
4-Row 2.5 3.5 4.5 5.2 5.6 7.3 8.5 10.4 12.0
6-Row 3.2 4.7 6.0 6.8 7.7 10.1 11.7 14.2 16.3
Chilled Water, 1/2 in. OD Tube,
Small Face Area
4-Row 2.1 3.3 3.9 4.1 5.1 6.3 7.3 8.7 9.8
6-Row 2.4 3.7 5.1 5.9 6.6 8.3 9.5 11.8 13.5
8-Row 2.7 4.1 6.4 7.4 8.4 10.7 12.1 14.7 17.2
Hot Water, 1/2 in. OD Tube
1-Row 0.5 0.8 1.0 1.3 1.5 1.8 2.1 2.5 2.9
2-Row 0.7 1.3 1.6 2.0 2.4 2.9 3.4 4.0 4.8
COOLING COILS
Chilled Water 1/2 in. OD Tube,
(4, 6 Row) Large Face Area
Face Area (sq ft) 3.63 5.90 7.90 9.54 11.18 14.91 17.71 21.6 25.0
Number of Tubes/Face 16 20 24 24 24 32 38 38 44
Finned Tube Length (in.) 26.1 34.0 37.9 45.8 53.7 53.7 53.7 65.5 65.5
Chilled Water 1/2 in. OD Tube,
(4, 6, 8 Row) Small Face Area
Face Area (sq ft) 2.72 4.72 6.58 7.95 9.32 12.12 13.98 17.1 20.5
Number of Tubes/Face 12 16 20 20 20 26 30 30 36
Finned Tube Length (in.) 26.1 34.0 37.9 45.8 53.7 53.7 53.7 65.5 65.5
DX 1/2 in. OD Tube,
(4, 6 Row) Large Face Area
Face Area (sq ft) 3.63 5.90 7.90 9.54 11.18 14.91 17.71 21.6 25.0
Finned Tube Length (in.) 26.1 34.0 37.9 45.8 53.7 53.7 53.7 65.5 65.5
DX 1/2 in. OD Tube,
(4, 6, 8 Row) Small Face Area
Face Area (sq ft) 2.72 4.72 6.58 7.95 9.32 12.12 13.98 17.1 20.5
Finned Tube Length (in.) 26.1 34.0 37.9 45.8 53.7 53.7 53.7 65.5 65.5
