MOUNTING OPTIONS
2
Attach the EOX
®
FL 150 securely to the bike using one of the brackets supplied.
NOTE: If other brackets are used, no guarantee can be given for secure attachment.
The EOX
®
FL 150 can be mounted both on the handlebars and on the fork crown. Please select the preferred mounting situation for your bike.
Standard mounting is on the handlebars. There are 2 different handlebar diameters available (31.5 mm or 35 mm). Select the diameter that matches
your handlebar model.
– First attach the handlebar clamp to the light body using the xing screw supplied.
– Then open the handlebar clamp and attach the clamp to your handlebars
Alternatively, you can also mount your EOX
®
FL 150 on the fork crown. To do this, loosen the bottom cover on the light body (R) Slide the fork mounting
adapter into the mounting rib and then secure the adapter with the enclosed screw (A). Cover the hole in the handlebar bracket with the enclosed site
cover (S). You can now mount your EOX
®
FL 150 on a standard fork holder.
WARNING! Make sure that the cable exit on the EOX
®
FL 150 always points straight down. This is the only way to ensure that the light image of the
EOX
®
FL 150 is ideally aligned and the headlight is protected from water in the best possible way.
2
R
S
A
R
S
A
31.5 mm
2
!
Reector
OPTIONAL
