10. Diagnostics

10. 1. Checking the address

On the graphic display terminal or integrated display terminal, check the address that has been coded on the switches using the [Address]

(AdrC) parameter in the [1.9 COMMUNICATION] (COM-) menu, [BACnet] (BACn) submenu.

This parameter cannot be modified.

The address switches are only read at power on, cycle the power to update value.

10. 2. Checking the communication

On the graphic display terminal, in the [1.2 - MONITORING] (SUP) menu [COMMUNICATION MAP] (CMM-) menu [DIAG NETWORK]

(nEt):

Contents of the DIAG NETWORK sub menu with a BACnet communication board:

10. 3. LEDs

The BACnet card has 2 LEDs, RUN and ERR, which are visible through the drive cover.

Parameter Comment

[Address] (ADRC) Displays the device address (configured by DIP switches).

The setting of these switches must (only) be done when the drive is powered off.

[Data rate used] (BDRU) Displays the baud rate used by the communication, these value may be useful when the baud rate

parameter is set to AUTO.

[Frame counter] (TFC) Displays the total number of frames received by the communication card since the last power ON.

[Invalid Frame counter] (EFC) Displays the total number of bad frames received by the communication card since the last power ON.

Green RUN LED Meaning Corrective action

Flashing intermittent Normal operation -

Flashing 3 times in 2 seconds,

Off for 1 second.

Waiting for Auto baud rate detection -

Red ERR LED Meaning Corrective action

Flashing intermittent Invalid message received • Check the environment (electromagnetic

compatibility).

• Check the communication parameter configuration

(protocol, speed, format).

• Check that the slave address is unique.

Flashing 5 times /second BACnet board failure • Replace the communication card.

Flashing 3 times /second

Off for 1 second

Communication loss detected • Check the environment (electromagnetic

compatibility).

• Check the card/drive connection

On 0.5s

Off O.5s

(with green LED also lighted)

Invalid configuration detected, causes an EPF2

fault

• ADRC is greater than Max Master parameter.

• CHCF : Wrong profile selected (must be Sep or Non-

Sep only).

• Not valid release of ATV61.

1.1

1.2

1.3

1.4

1.5

2.1

2.2

2.3

2.4

2.5

RUN (green)

ERR (red)
