9. Configuration

9. 4. Communication faults

A BACnet fault is triggered if the BACnet card does not receive any BACnet messages (regardless of address) at its address within a

predefined time period (time out defined by tLP). All BACnet request types are taken into account (read, write, etc.).

The response of the drive in the event of a BACnet communication fault can be configured.

The values of the [Network fault mgt] (CLL) parameter, which trigger a [Com. network] (CnF) drive fault, are:

The values of the [Network fault mgt] (CLL) parameter, which do not trigger a drive fault, are:

The fallback speed can be configured via the [Fallback speed]

(LFF) parameter in the [1.8 – FAULT MANAGEMENT] (FLt-) menu.

Configuration can be performed using the graphic display terminal or

integrated display terminal using the [Network fault mgt] (CLL)

parameter in the [1.8 FAULT MANAGEMENT] (FLt-) menu, [COM.

FAULT MANAGEMENT] (CLL-) submenu.

RDY NET +0.00Hz 0A

COM. FAULT MANAGEMENT

Network fault mgt : Freewheel

CANopen fault mgt : Freewheel

Modbus fault mgt : Freewheel

Code Quick

Value Meaning

[Freewheel] (YES) Freewheel stop (factory setting)

[Ramp stop] (rMP) Stop on ramp

[Fast stop] (FSt) Fast stop

[DC injection]

(dCI) DC injection stop

Value Meaning

[Ignore] (nO) Fault ignored

[Per STT] (Stt) Stop according to configuration of [Type of stop]

(Stt).

[fallback spd] (LFF) Switch to fallback speed, maintained as long as the fault is present and the run command is not disabled.

[Spd maint.]

(rLS)

The drive maintains the speed at the time the fault occurred, as long as the fault persists and the run

command has not been removed.
