11
Panel descriptions and operations
Rear panel (connecting your equipment)
* To prevent malfunction and equipment failure, always turn down the volume, and turn o all the units before making any connections.
Power cord
To AC outlet
A B D
E
F
C
G
H
I
USB ash drive
Computer
Audio device
Studio equipment or
mixing consoles
Monitor speakers
(with built-in amp)
Expression pedal
or footswitch
MIDI/DIN SYNC device
Analog synthesizers
or Eurorack modules
equipped with CV/gate
input jacks
* Be sure to use the included USB cable, and
connect the side with the attached ferrite core to
your computer. Do not remove the ferrite core, as
this helps prevent electromagnetic noise.
