8
Connecting the TMC-6
Attaching the TMC-6 to a Drum Stand
You can attach the TMC-6 to a drum stand (optional).
1.
Attach the stand holder to the TMC-6.
Using the provided screws, attach the holder so the unit is oriented as shown
in the diagram.
fig.02-01
(928)(929)
2.
Attach the stand holder to the drum stand.
The model MDH-7U/10U is required if installing onto drum stands such as
the MDS-6/7U/8/10.
For instructions for assembling the drum stand, refer to the manual that came
with your drum stand.
Connecting Drum Pads
■
Trigger Inputs and the Pads You Can Use
Connect pads to the trigger inputs as shown in the next page. Depending on
the compatibility between pads and trigger inputs, you may be unable to use
pads.
After connecting pads, always be sure to select the appropriate
Trigger Type
setting (p. 11).
(921)
Narrow
Wide
Use the 12 mm screws (M5
x 12) provided with the
TMC-6. Use of other
screws may result in
damage to the unit.
When turning the unit
upside-down, get a bunch of
newspapers or magazines,
and place them under the
four corners or at both ends
to prevent damage to the
b
uttons and controls. Also,
you should try to orient the
unit so no buttons or
controls get damaged.
When turning the unit
upside-down, handle with
care to avoid dropping it, or
allowing it to fall or tip over.
To attach the TMC-6 to a
cymbal stand or other such
stand, you may want to
use the optional APC-33
All Purpose Clamp to
secure the stand holder. It
can be attached to a pipe of
10.5 mm–30 mm radius.
To prevent malfunction
and/or damage to
speakers or other devices,
always turn down the
volume, and turn off the
power on all devices
b
efore making any
connections.
