10
Restoring the Factory Settings (FACTORY RESET)
This procedure restores the original, factory-set values stored in the TMC-6.
1.
While holding down the [TRIGGER SELECT] button and [EDIT] button,
turn on the power.
The message below appears in the display and the [EDIT] button’s indicator
starts blinking.
fig.03-01
2.
Press the [EDIT] button, and the Factory Reset operation will be executed.
To cancel the operation, turn the power off, then on again.
Once the Factory Reset has been completed, the TMC-6 switches to Play
mode.
The factory default parameters are set as shown below.
* All set to 60 (Bongo) from Memory No. 5 to 8. From Memory No. 9 to 12 are the same
as from Memory No. 1 to 4.
The following are common to all memories.
MIDI CHANNEL: TRIG 1 Head: 10; others: ,
MIDI PRG CHG: ,
VELOCITY CURVE:
Memory No. 1:
Settings for the GM/GS or other multi-timbral sound modules.
Memory No. 2:Settings for adding pads to the TD series.
Memory No. 3:
Settings for using acoustic drum triggers (Kick, Snare, and Tom)
Memory No. 4:Settings for connecting 7 pads to the TMC-6. (Connect two
pads using PCS-31 cable to TRIG 2. Change the trigger type of
TRIG 2 RIM to
or other suitable one.
)
* To set the TRIG 5 closed note number, in the Note Number settings screen, hold
down the hi-hat control pedal and strike the pad connected to TRIG 5. The closed note
number appears; you can then set the value.
If a Message Error Appears
If all of the TMC-6’s indicators flash while the message below appears in the
display, it may be that the unit’s internal memory has been corrupted.
fig.03-02
Press the [EDIT] button to put the TMC-6 in a state allowing Factory Reset to
be carried out.
Press the [EDIT] button again to execute Factory Reset.
If this does not resolve the problem, contact your dealer or a nearby Roland service center.
TRIGGER
INPUT
1
2 3 4 5 6 HH Ctrl
Head Rim Head Rim Head Rim Head Rim
Head
open
Rim
open
Head
closed
Rim
closed
Head
Rim -
TRIGGER
TYPE
memory
No. 1
Note No.
36
35 38 40 45 41 49 57 46 46 42 42 51 53 44
Kick Snare Tom Crash Open HH
Closed
HH
Ride Pedal HH
memory
No. 2
Note No.
60
61 62 63 64 65 66 67 68 69 73 74 70 71 72
Bongo Conga Timbales Agogo
Cabasa
Guiro
Maracas
Whistle
memory
No. 3
Note No.
36
35 38 40 48 48 45 45 43 43 41 41 41 41 44
Kick Snare Tom 1 Tom 2 Tom 3 Tom 4 Pedal HH
memory
No. 4
Note No.
38
40 36 48 45 41 49 57 46 46 42 42 51 53 44
Snare Kick Tom 1 Tom 2 Tom 3 Crash Open HH Closed HH Ride Pedal HH
This operation deletes all
of the settings that have
b
een stored on the TMC-6.
Exercise due caution when
carrying out Factory Reset.
After the [EDIT] button is
pressed, do not turn off
power to the TMC-6 until
the [EDIT] button’s light
has gone out.
Hi-hat control is used
when a pad connected to
TRIG 5 is used as a hi-hat.
If the hi-hat control is not
used, only the open sound
will be heard.
Carrying out a Factory
Reset deletes all of the
current TMC-6’s settings,
and returns them to the
original factory settings.
