Roland EARTH Piano handleiding
Handleiding
Je bekijkt pagina 55 van 59
5555
MFX parameter list
Parameter Value Explanation
Speaker Type LINE, OLD, NEW,
WURLY, TWIN
Type of speaker
If LINE is selected, the sound will
not be sent through the speaker
simulation.
OD Switch OFF, ON Overdrive on/o
OD Gain 0–127 Overdrive input level
OD Drive 0–127 Degree of distortion
Also changes the volume.
Level 0–127 Output Level
EPAmpSim Ó Phaser
L in
R in
L out
R out
Resonance
Mix
PhaserEP Amp Speaker
Parameter Value Explanation
Type Type of amp
OLDCASE A standard electric piano sound of
the early 70s
NEWCASE A standard electric piano sound of
the late 70s and early 80s
Bass -50–+50 Amount of low-frequency boost/cut
Treble -50–+50 Amount of high-frequency boost/cut
Phaser
Switch
OFF, ON Phaser on/o
Phaser Rate
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Phaser Rate
(Hz)
0.05–10.00 [Hz] Frequency of modulation
Phaser Rate
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Phaser
Manual
0–127 Adjusts the basic frequency from
which the sound will be modulated.
Phaser Depth 0–127 Depth of modulation
Parameter Value Explanation
Phaser
Resonance
0–127 Amount of feedback
Phaser Mix 0–127 Level of the phase-shifted sound
Speaker Type LINE, OLD, NEW,
WURLY, TWIN
Type of speaker
If LINE is selected, the sound will
not be sent through the speaker
simulation.
OD Switch OFF, ON Overdrive on/o
OD Gain 0–127 Overdrive input level
OD Drive 0–127 Degree of distortion
Also changes the volume.
Level
0–127 Output Level
EPAmpSim Ó Delay
L out
R out
Balance W
Feedback
Balance W
Balance D
Balance D
L in
R in
Time Ctrl
Delay
EP Amp
Speaker
Speaker
Parameter Value Explanation
Type Type of amp
OLDCASE A standard electric piano sound of
the early 70s
NEWCASE A standard electric piano sound of
the late 70s and early 80s
Bass -50–+50 Amount of low-frequency boost/cut
Treble -50–+50 Amount of high-frequency boost/cut
Delay Switch OFF, ON Delay on/o
Delay Time
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Parameter Value Explanation
Delay Time
(msec)
1–1300 [msec] Adjusts the time from the original
sound until delay sounds is heard.
Delay Time
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Delay Accel 0–15 Speed at which the current delay
time changes to the specied delay
time when you change the delay
time.
The speed of the pitch change will
change simultaneously with the
delay time.
Delay
Feedback
-98–+98 [%] Adjusts the proportion of the delay
sound that is fed back into the eect.
Negative (-) settings will invert the
phase.
Delay HF
Damp
200, 250, 315,
400, 500, 630,
800, 1000, 1250,
1600, 2000,
2500, 3150,
4000, 5000,
6300, 8000,
BYPASS [Hz]
Frequency at which the high-
frequency portion of the delay
sound will be cut (BYPASS: no cut)
Delay
Balance
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
delay (W) and the sound that is not
sent through the delay (D).
Speaker Type LINE, OLD, NEW,
WURLY, TWIN
Type of speaker
If LINE is selected, the sound will
not be sent through the speaker
simulation.
OD Switch OFF, ON Overdrive on/o
OD Gain 0–127 Overdrive input level
OD Drive 0–127 Degree of distortion
Also changes the volume.
Level 0–127 Output Level
