5454
MFX parameter list
Parameter Value Explanation
Tremolo
Speed (sync
sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Tremolo
Speed (Hz)
0.05–10.00 [Hz] Rate of the tremolo eect
Tremolo
Speed (note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Tremolo
Depth
0–127 Depth of the tremolo eect
Tremolo Duty -10–+10 Adjusts the duty cycle of the LFO
waveform used to apply tremolo.
Speaker Type LINE, OLD, NEW,
WURLY, TWIN
Type of speaker
If LINE is selected, the sound will
not be sent through the speaker
simulation.
OD Switch OFF, ON Overdrive on/o
OD Gain 0–127 Overdrive input level
OD Drive 0–127 Degree of distortion
Also changes the volume.
Level 0–127 Output Level
EPAmpSim Ó Chorus
L outL in
R in
R out
Balance W
Balance W
Balance D
Balance D
SpeakerEP Amp Chorus
Parameter Value Explanation
Type Type of amp
OLDCASE A standard electric piano sound of
the early 70s
NEWCASE A standard electric piano sound of
the late 70s and early 80s
Bass -50–+50 Amount of low-frequency boost/cut
Parameter Value Explanation
Treble -50–+50 Amount of high-frequency boost/cut
Chorus
Switch
OFF, ON Chorus on/o
Chorus Pre
Delay
0.0–100 [msec] Adjusts the delay time from when
the direct sound begins until the
chorus sound is heard.
Chorus Rate
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Chorus Rate
(Hz)
0.05–10.00 [Hz] Frequency of modulation
Chorus Rate
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Chorus
Depth
0–127 Depth of modulation
Chorus
Balance
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
chorus (W) and the sound that is not
sent through the chorus (D).
Speaker Type LINE, OLD, NEW,
WURLY, TWIN
Type of speaker
If LINE is selected, the sound will
not be sent through the speaker
simulation.
OD Switch OFF, ON Overdrive on/o
OD Gain 0–127 Overdrive input level
OD Drive 0–127 Degree of distortion
Also changes the volume.
Level 0–127 Output Level
EPAmpSim Ó Flanger
L out
R out
Balance W
Feedback
Balance W
Balance D
Balance D
L in
R in
FlangerEP Amp Speaker
Parameter Value Explanation
Type Type of amp
OLDCASE A standard electric piano sound of
the early 70s
NEWCASE A standard electric piano sound of
the late 70s and early 80s
Bass -50–+50 Amount of low-frequency boost/cut
Treble -50–+50 Amount of high-frequency boost/cut
Flanger
Switch
OFF, ON Flanger on/o
Flanger Pre
Delay
0.0–100 [msec] Adjusts the time from the original
sound until anger sounds is heard.
Flanger Rate
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Flanger Rate
(Hz)
0.05–10.00 [Hz] Frequency of modulation
Flanger Rate
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Flanger
Depth
0–127 Depth of modulation
Flanger
Feedback
-98–+98 [%] Adjusts the proportion of the anger
sound that is fed back into the eect.
Negative (-) settings will invert the
phase.
Flanger
Balance
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
anger (W) and the sound that is not
sent through the anger (D).
