MFX parameter list
Enhancer Ó Chorus
L out
R out
Balance D
Balance W
Balance W
Balance D Mix
Mix
L in
R in
Chorus
Enhancer
Enhancer
Parameter Value Explanation
Enhancer
Sens
0–127 Sensitivity of the enhancer
Enhancer Mix 0–127 Level of the overtones generated by
the enhancer
Chorus Pre
Delay
0.0–100 [msec] Adjusts the time from the original
sound until chorus sounds is heard.
Chorus Rate
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Chorus Rate
(Hz)
0.05–10.00 [Hz] Frequency of modulation
Chorus Rate
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Chorus
Depth
0–127 Depth of modulation
Chorus
Balance
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
chorus (W) and the sound that is not
sent through the chorus (D).
Level 0–127 Output Level
Enhancer Ó Flanger
Balance D
Balance D
Mix
Mix
L out
R out
Balance W
Balance W W
L in
R in
Feedback
Flanger
Enhancer
Enhancer
Parameter Value Explanation
Enhancer
Sens
0–127 Sensitivity of the enhancer
Enhancer Mix 0–127 Level of the overtones generated by
the enhancer
Flanger Pre
Delay
0.0–100 [msec] Adjusts the delay time from when
the direct sound begins until the
anger sound is heard.
Flanger Rate
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Flanger Rate
(Hz)
0.05–10.00 [Hz] Frequency of modulation
Flanger Rate
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Flanger
Depth
0–127 Depth of modulation
Flanger
Feedback
-98–+98 [%] Adjusts the proportion of the anger
sound that is fed back into the eect.
Negative (-) settings will invert the
phase.
Flanger
Balance
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
anger (W) and the sound that is not
sent through the anger (D).
Level 0–127 Output Level
Enhancer Ó Delay
Balance D
Balance D
Mix
Mix
L out
R out
Balance W
Balance W
L in
R in
Feedback
Enhancer
Enhancer
Delay
Parameter Value Explanation
Enhancer
Sens
0–127 Sensitivity of the enhancer
Enhancer Mix 0–127 Level of the overtones generated by
the enhancer
Delay Time
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Delay Time
(msec)
1–2600 [msec] Adjusts the delay time from when
the direct sound begins until the
delay sound is heard.
Delay Time
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Delay
Feedback
-98–+98 [%] Adjusts the proportion of the delay
sound that is fed back into the eect.
Negative (-) settings will invert the
phase.
Delay HF
Damp
200, 250, 315,
400, 500, 630,
800, 1000, 1250,
1600, 2000,
2500, 3150,
4000, 5000,
6300, 8000,
BYPASS [Hz]
Adjusts the frequency above which
sound fed back to the eect will be
cut. If you do not want to cut the
high frequencies, set this parameter
to BYPASS.
Delay
Balance
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
delay (W) and the sound that is not
sent through the delay (D).
Level 0–127 Output Level
