MFX parameter list
Multi Tap Delay
This eect provides four delays. Each of the Delay Time parameters can
be set to a note length based on the selected tempo. You can also set the
panning and level of each delay sound.
R out
L out
Balance W
Balance W
Balance D
L in
Balance D
Delay 1
Feedback
Delay 2
Delay 3
Delay 4
R in
Multi Tap
Delay
2-Band EQ
2-Band EQ
Parameter Value Explanation
Delay 1 Time
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Delay 1 Time
(msec)
1–2600 [msec] Adjusts the delay time from when
the direct sound begins until the
Delay 1 sound is heard.
Delay 1 Time
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Delay 2 Time
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Delay 2 Time
(msec)
1–2600 [msec] Adjusts the delay time from when
the direct sound begins until the
Delay 2 sound is heard.
Delay 2 Time
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Delay 3 Time
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Parameter Value Explanation
Delay 3 Time
(msec)
1–2600 [msec] Adjusts the delay time from when
the direct sound begins until the
Delay 3 sound is heard.
Delay 3 Time
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Delay 4 Time
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Delay 4 Time
(msec)
1–2600 [msec] Adjusts the delay time from when
the direct sound begins until the
Delay 4 sound is heard.
Delay 4 Time
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Delay 1
Feedback
-98–+98 [%] Adjusts the proportion of the delay
sound that is fed back into the eect.
Negative (-) settings will invert the
phase.
HF Damp 200, 250, 315,
400, 500, 630,
800, 1000, 1250,
1600, 2000,
2500, 3150,
4000, 5000,
6300, 8000,
BYPASS [Hz]
Adjusts the frequency above which
sound fed back to the eect is
ltered out. If you don’t want to lter
out any high frequencies, set this
parameter to BYPASS.
Delay 1 Pan L64–63R Stereo location of Delays 1–4
Delay 2 Pan
Delay 3 Pan
Delay 4 Pan
Delay 1 Level 0–127 Volume of Delays 1–4
Delay 2 Level
Delay 3 Level
Delay 4 Level
Low Gain -15–+15 [dB] Amount of boost/cut for the low-
frequency range
High Gain -15–+15 [dB] Amount of boost/cut for the high-
frequency range
Parameter Value Explanation
Balance D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the eect sound (W)
Level 0–127 Output Level
