MFX parameter list
Reverse Delay
This is a reverse delay that adds a reversed and delayed sound to the input
sound. A tap delay is connected immediately after the reverse delay.
R out
L out
L in
D1
Rev
D2D3
Feedback
R in
Rev. Delay
2-Band
EQ
2-Band
EQ
Delay
Parameter Value Explanation
Threshold 0–127 Volume at which the reverse delay
will begin to be applied
Rev Delay
Time (sync
sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Rev Delay
Time (msec)
1–1300 [msec] Delay time from when sound is input
into the reverse delay until the delay
sound is heard
Rev Delay
Time (note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Rev Delay
Feedback
-98–+98 [%] Proportion of the delay sound that
is to be returned to the input of the
reverse delay (negative (-) values
invert the phase)
Rev Delay HF
Damp
200, 250, 315,
400, 500, 630,
800, 1000, 1250,
1600, 2000,
2500, 3150,
4000, 5000,
6300, 8000,
BYPASS [Hz]
Frequency at which the high-
frequency content of the reverse-
delayed sound will be cut (BYPASS:
no cut)
Rev Delay
Pan
L64–63R Panning of the reverse delay sound
Parameter Value Explanation
Rev Delay
Level
0–127 Volume of the reverse delay sound
Delay 1 Time
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Delay 1 Time
(msec)
1–1300 [msec] Delay time from when sound is input
into the tap delay until the delay
sound is heard
Delay 1 Time
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Delay 2 Time
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Delay 2 Time
(msec)
1–1300 [msec] Delay time from when sound is input
into the tap delay until the delay
sound is heard
Delay 2 Time
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Delay 3 Time
(sync sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Delay 3 Time
(msec)
1–1300 [msec] Delay time from when sound is input
into the tap delay until the delay
sound is heard
Delay 3 Time
(note)
1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Delay 3
Feedback
-98–+98 [%] Proportion of the delay sound that
is to be returned to the input of the
tap delay (negative (-) values invert
the phase)
Parameter Value Explanation
Delay HF
Damp
200, 250, 315,
400, 500, 630,
800, 1000, 1250,
1600, 2000,
2500, 3150,
4000, 5000,
6300, 8000,
BYPASS [Hz]
Frequency at which the hi-frequency
content of the tap delay sound will
be cut (BYPASS: no cut)
Delay 1 Pan
L64–63R Panning of the tap delay sounds
Delay 2 Pan
L64–63R
Delay 1 Level
0–127 Volume of the tap delay sounds
Delay 2 Level
0–127
Low Gain
-15–+15 [dB] Amount of boost/cut for the low-
frequency range
High Gain
-15–+15 [dB] Amount of boost/cut for the high-
frequency range
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the delay sound (W)
Level
0–127 Output Level
