3030
MFX parameter list
Auto Pan
Cyclically modulates the stereo location of the sound.
L in L out
R outR in
Auto Pan 2-Band EQ
Auto Pan 2-Band EQ
Parameter Value Explanation
Mod Wave TRI, SQR, SIN,
SAW1, SAW2,
TRP
Modulation wave
TRI: Triangle wave
SQR: Square wave
SIN: Sine wave
SAW1/2: Sawtooth wave
TRP: Trapezoidal wave
SAW1 SAW2
R R
L L
Rate (sync
sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Rate (Hz) 0.05–10.00 [Hz] Frequency of the change
Rate (note) 1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Depth 0–127 Depth to which the eect is applied
Low Gain -15–+15 [dB] Amount of boost/cut for the low-
frequency range
High Gain -15–+15 [dB] Amount of boost/cut for the high-
frequency range
Level 0–127 Output Level
Slicer
By applying successive cuts to the sound, this eect turns a conventional
sound into a sound that appears to be played as a backing phrase. This is
especially eective when applied to sustain-type sounds.
L in L out
R outR in
Slicer
Slicer
Parameter Value Explanation
Step 01–16 0–127 Level at each step
Rate (sync
sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Rate (Hz) 0.05–10.00 [Hz] Rate at which the 16-step sequence
will cycle
Rate (note) 1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Attack 0–127 Speed at which the level changes
between steps
Input Sync
Sw
OFF, ON Species whether an input note will
cause the sequence to resume from
the rst step of the sequence (ON) or
not (OFF)
Input Sync
Threshold
0–127 Volume at which an input note will
be detected
Mode LEGATO, SLASH Sets the manner in which the volume
changes as one step progresses to
the next.
LEGATO: The change in volume
from one step’s level to the next
remains unaltered. If the level of a
following step is the same as the one
preceding it, there is no change in
volume.
SLASH: The level is momentarily set
to 0 before progressing to the level
of the next step.
This change in volume occurs even if
the level of the following step is the
same as the preceding step.
Parameter Value Explanation
Shue 0–127 Timing of volume changes in levels
for even-numbered steps (step 2,
step 4, step 6...).
The higher the value, the later the
beat progresses.
Level 0–127 Output Level
Rotary
This simulates a classic rotary speaker of the past. Since the operation of the
high-frequency and low-frequency rotors can be specied independently,
the distinctive modulation can be reproduced realistically. This is most
eective on organ patches.
L in
R in
L out
R out
Rotary
Parameter Value Explanation
Speed SLOW, FAST The rotational speed of the low
frequency rotor and high frequency
rotor
SLOW: Slows down the rotation to
the Slow Rate.
FAST: Speeds up the rotation to the
Fast Rate.
Woofer Slow
Speed
0.05–10.00 [Hz] Slow speed (SLOW) of the low
frequency rotor
Woofer Fast
Speed
0.05–10.00 [Hz] Fast speed (FAST) of the low
frequency rotor
Woofer
Acceleration
0–15 The speed at which the low
frequency rotor’s rotation changes
when you switch between rotation
speeds
Woofer Level 0–127 Volume of the low frequency rotor
Tweeter Slow
Speed
0.05–10.00 [Hz] Settings of the high frequency rotor
The parameters are the same as for
the low frequency rotor
Tweeter Fast
Speed
0.05–10.00 [Hz]
Tweeter
Acceleration
0–15
Tweeter
Level
0–127
Separation 0–127 Spatial dispersion of the sound
Level 0–127 Output Level
