MFX parameter list
VK Rotary
This type provides modied response for the rotary speaker, with the low
end boosted further. This eect features the same specications as the VK-
7’s built-in rotary speaker.
L in
R in
L out
R out
Rotary
2-Band EQ
2-Band EQ
Parameter Value Explanation
Speed SLOW, FAST Rotational speed of the rotating
speaker
SLOW: Slow
FAST: Fast
Brake OFF, ON Switches the rotation of the rotary
speaker.
When this is turned on, the rotation
will gradually stop. When it is turned
o, the rotation will gradually
resume.
Woofer Slow
Speed
0.05–10.00 [Hz] Low-speed rotation speed of the
woofer
Woofer Fast
Speed
0.05–10.00 [Hz] High-speed rotation speed of the
woofer
Woofer Trans
Up
0–127 Adjusts the rate at which the
woofer rotation speeds up when
the rotation is switched from Slow
to Fast.
Woofer Trans
Down
0–127 Adjusts the rate at which the
woofer rotation speeds up when
the rotation is switched from Fast
to Slow.
Woofer Level 0–127 Volume of the woofer
Tweeter Slow
Speed
0.05–10.00 [Hz] Settings of the tweeter
The parameters are the same as for
the woofer.
Tweeter Fast
Speed
0.05–10.00 [Hz]
Tweeter
Trans Up
0–127
Tweeter
Trans Down
0–127
Tweeter
Level
0–127
Spread 0–10 Stereo spread of the rotary speaker
sound
Parameter Value Explanation
Low Gain -15–+15 [dB] Amount of boost/cut for the low-
frequency range
High Gain -15–+15 [dB] Amount of boost/cut for the high-
frequency range
Level 0–127 Output Level
OD Switch OFF, ON Overdrive on/o
OD Gain 0–127 Overdrive input level
Higher values will increase the
distortion.
OD Drive 0–127 Degree of distortion
OD Level 0–127 Volume of the overdrive
DRIVE/AMP
Overdrive
This is an overdrive that provides heavy distortion.
L in
R in
L out
R out
Pan L
Pan R
Amp
Smlator
Overdrive 2-Band EQ
Parameter Value Explanation
Drive 0–127 Degree of distortion
Also changes the volume.
Tone 0–127 Sound quality of the Overdrive eect
Amp Sw OFF, ON Turns the Amp Simulator on/o.
Amp Type SMALL, BUILT-IN,
2-STACK,
3-STACK
Type of guitar amp
SMALL: Small amp
BUILT-IN: Single-unit type amp
2-STACK: Large double stack amp
3-STACK: Large triple stack amp
Low Gain -15–+15 [dB] Amount of boost/cut for the low-
frequency range
High Gain -15–+15 [dB] Amount of boost/cut for the high-
frequency range
Pan L64–63R Stereo location of the output sound
Level 0–127 Output Level
Distortion
Produces a more intense distortion than Overdrive.
L in
R in
L out
R out
Pan L
Pan R
Amp
Smlator
Distortion 2-Band EQ
Parameter Value Explanation
Drive 0–127 Degree of distortion
Also changes the volume.
Tone 0–127 Sound quality of the Overdrive eect
Amp Sw OFF, ON Turns the Amp Simulator on/o.
