2929
MFX parameter list
SDD-320 (DIMENSION D)
This models Roland’s DIMENSION D (SDD-320). It provides a clear chorus
sound.
L in L out
R outR in
SDD-320
2-Band EQ
2-Band EQ
Parameter Value Explanation
Mode
1, 2, 3, 4, 1+4,
2+4, 3+4
Switches the mode.
Low Gain
-15–+15 [dB] Amount of boost/cut for the low-
frequency range
High Gain
-15–+15 [dB] Amount of boost/cut for the high-
frequency range
Level
0–127 Output Level
JUNO-106 Chorus
This models the chorus eects of the Roland JUNO-106.
L out
R out
L in
R in
Balance D
Balance D
Balance W
Balance W
Chorus
Chorus
Noise
Generator
Noise
Generator
Parameter Value Explanation
Mode I, II, I+II, JX I, JX II Type of Chorus
I+II: The state in which two buttons
are pressed simultaneously.
Noise Level 0–127 Volume of the noise produced by
chorus
Balance D100:0W–
D0:100W
Volume balance between the dry
sound (D) and eect sound (W)
Level 0–127 Output Level
MODULATION
Ring Modulator
This is an eect that applies amplitude modulation (AM) to the input signal,
producing bell-like sounds. You can also change the modulation frequency
in response to changes in the volume of the sound sent into the eect.
L in L out
R outR in
Ring Mod 2-Band EQ
Ring Mod 2-Band EQ
Parameter Value Explanation
Frequency 0–127 Adjusts the frequency at which
modulation is applied.
Sens 0–127 Adjusts the amount of frequency
modulation applied.
Polarity UP, DOWN Determines whether the frequency
modulation moves towards higher
frequencies or lower frequencies.
UP: The lter will change toward a
higher frequency.
DOWN: The lter will change toward
a lower frequency.
Low Gain -15–+15 [dB] Amount of boost/cut for the low-
frequency range
High Gain -15–+15 [dB] Amount of boost/cut for the high-
frequency range
Balance D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the eect sound (W)
Level 0–127 Output Level
Tremolo
Cyclically changes the volume.
L in L out
R outR in
Tremolo 2-Band EQ
Tremolo 2-Band EQ
Parameter Value Explanation
Mod Wave TRI, SQR, SIN,
SAW1, SAW2,
TRP
Modulation Wave
TRI: Triangle wave
SQR: Square wave
SIN: Sine wave
SAW1/2: Sawtooth wave
TRP: Trapezoidal wave
SAW1 SAW2
Rate (sync
sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Rate (Hz) 0.05–10.00 [Hz] Frequency of the change
Rate (note) 1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Depth 0–127 Depth to which the eect is applied
Low Gain -15–+15 [dB] Amount of boost/cut for the low-
frequency range
High Gain
-15–+15 [dB] Amount of boost/cut for the high-
frequency range
Level
0–127 Output Level
