MFX parameter list
Low Boost
Boosts the volume of the lower range, creating powerful lows.
L in L out
R outR in
Low Boost 2-Band EQ
Low Boost 2-Band EQ
Parameter Value Explanation
Boost
Frequency
50, 56, 63, 71,
80, 90, 100, 112,
125 [Hz]
Center frequency at which the lower
range will be boosted
Boost Gain 0–+12 [dB] Center frequency at which the lower
range will be boosted
Boost Width WIDE, MID,
NARROW
Width of the lower range that will be
boosted
Low Gain -15–+15 [dB] Amount of boost/cut for the low-
frequency range
High Gain -15–+15 [dB] Amount of boost/cut for the high-
frequency range
Level 0–127 Output Level
Super Filter
This is a lter with an extremely sharp slope. The cuto frequency can be
varied cyclically.
L in L out
R outR in
Super Filter
Super Filter
Parameter Value Explanation
Filter Type LPF, BPF, HPF,
NOTCH
Type of lter
Frequency range that will pass
through each lter
LPF: Frequencies below the cuto
BPF: Frequencies in the region of
the cuto
HPF: Frequencies above the cuto
NOTCH: Frequencies other than the
region of the cuto
Filter Slope -12, -24, -36 [dB] Amount of attenuation per octave
-12 dB: Gentle, -24 dB: Steep, -36
dB: Extremely steep
Parameter Value Explanation
Filter Cuto 0–127 Cuto frequency of the lter
Increasing this value will raise the
cuto frequency.
Filter
Resonance
0–100 Filter resonance level
Increasing this value will emphasize
the region near the cuto frequency.
Filter Gain 0–+12 [dB] Amount of boost for the lter output
Modulation
Sw
OFF, ON On/o switch for cyclic change
Modulation
Wave
TRI, SQR, SIN,
SAW1, SAW2
How the cuto frequency will be
modulated
TRI: Triangle wave
SQR: Square wave
SIN: Sine wave
SAW1: Sawtooth wave (upward)
SAW2: Sawtooth wave (downward)
SAW1 SAW2
Rate (sync
sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
Rate (Hz) 0.05–10.00 [Hz] Frequency of modulation
Rate (note) 1/64T, 1/64,
1/32T, 1/32,
1/16T, 1/32D,
1/16, 1/8T,
1/16D, 1/8, 1/4T,
1/8D, 1/4, 1/2T,
1/4D, 1/2, 1/1T,
1/2D, 1/1, 2/1T,
1/1D, 2/1
Depth 0–127 Depth of modulation
Attack 0–127 Speed at which the cuto frequency
will change. This is eective if
Modulation Wave is SQR, SAW1, or
SAW2.
Level 0–127 Output Level
Multi Mode Filter
This is a lter that is adjusted for eective use in a DJ performance.
L in
R in
L out
R out
Multimode
Filter
Multimode
Filter
Multimode
Filter
Multimode
Filter
Parameter Value Explanation
Filter Type LPF/HPF, LPF,
HPF, BPF
Type of lter
LPF/HPF: The lter type is
automatically switched according to
the Filter Tone parameter value.
Filter Tone 0–255 Frequency at which the lter
operates
Filter Color 0–255 Filter resonance level
Higher values more strongly
emphasize the region of the
operating frequency.
Filter Slope -12, -24, -36 [dB] Amount of attenuation per octave
-12 dB: Gentle
-24 dB: Steep
-36 dB: Extremely steep
Filter Gain 0–+12 [dB] Amount of boost for the lter output
Level 0–127 Output Level
Step Filter
This is a lter whose cuto frequency can be modulated in steps. You can
specify the pattern by which the cuto frequency will change.
L in L out
R outR in
Step Filter
Step Filter
Parameter Value Explanation
Step 01–16 0–127 Cuto frequency at each step
Rate (sync
sw)
OFF, ON Synchronize to the tempo of the
DAW if this is ON.
