MFX parameter list
Parameter Value Explanation
S Input Gain -12.00–+12.00
[dB]
Volume of left/right input signals
whose signals are considerably out
of phase
S Low
Frequency
20, 25, 31, 40,
50, 63, 80, 100,
125, 160, 200,
250, 315, 400
[Hz]
Frequency of the low range
S Low Gain -12.00–+12.00
[dB]
Amount of boost/cut for the low-
frequency range
S Mid1
Frequency
200, 250, 315,
400, 500, 630,
800, 1000, 1250,
1600, 2000,
2500, 3150,
4000, 5000,
6300, 8000 [Hz]
Frequency of the middle range 1
S Mid1 Gain -12.00–+12.00
[dB]
Gain of the middle range 1
S Mid1 Q 0.5, 1.0, 2.0, 4.0,
8.0
Width of the middle range 1
Higher values make the width more
narrow.
S Mid2
Frequency
200, 250, 315,
400, 500, 630,
800, 1000, 1250,
1600, 2000,
2500, 3150,
4000, 5000,
6300, 8000 [Hz]
Frequency of the middle range 2
S Mid2 Gain -12.00–+12.00
[dB]
Gain of the middle range 2
S Mid2 Q 0.5, 1.0, 2.0, 4.0,
8.0
Width of the middle range 2
Higher values make the width more
narrow.
S Mid3
Frequency
200, 250, 315,
400, 500, 630,
800, 1000, 1250,
1600, 2000,
2500, 3150,
4000, 5000,
6300, 8000 [Hz]
Frequency of the middle range 3
S Mid3 Gain -12.00–+12.00
[dB]
Gain of the middle range 3
S Mid3 Q 0.5, 1.0, 2.0, 4.0,
8.0
Width of the middle range 3
Higher values make the width more
narrow.
Parameter Value Explanation
S High
Frequency
2000, 2500,
3150, 4000,
5000, 6300,
8000, 10000,
12500, 16000
[Hz]
Frequency of the high range
S High Gain -12.00–+12.00
[dB]
Amount of boost/cut for the high-
frequency range
Level 0–127 Output Level
Spectrum
This is a stereo spectrum. Spectrum is a type of lter which modies the
timbre by boosting or cutting the level at specic frequencies.
L in L out
R outR in
Spectrum
Spectrum
Parameter Value Explanation
Band1 (250
Hz)
-15–+15 [dB] Gain of each frequency band
Band2 (500
Hz)
Band3 (1000
Hz)
Band4 (1250
Hz)
Band5 (2000
Hz)
Band6 (3150
Hz)
Band7 (4000
Hz)
Band8 (8000
Hz)
Q 0.5, 1.0, 2.0, 4.0,
8.0
Simultaneously adjusts the width
of the adjusted ranges for all the
frequency bands.
Level 0–127 Output Level
Isolator
This is an equalizer which cuts the volume greatly, allowing you to add a
special eect to the sound by cutting the volume in varying ranges.
L in L out
R outR in
Isolator Low Boost
Isolator Low Boost
Parameter Value Explanation
Boost/Cut
Low
-60–+4 [dB] These boost and cut each of the
High, Middle, and Low frequency
ranges.
At -60 dB, the sound becomes
inaudible. 0 dB is equivalent to the
input level of the sound.
Boost/Cut
Mid
-60–+4 [dB]
Boost/Cut
High
-60–+4 [dB]
Anti Phase
Low Sw
OFF, ON Turns the Anti-Phase function on and
o for the Low frequency ranges.
When turned on, the counter-
channel of stereo sound is inverted
and added to the signal.
Anti Phase
Low Level
0–127 Adjusts the level settings for the Low
frequency ranges.
Adjusting this level for certain
frequencies allows you to lend
emphasis to specic parts (This is
eective only for stereo source.).
Anti Phase
Mid Sw
OFF, ON Settings of the Anti-Phase function
for the Middle frequency ranges.
The parameters are the same as for
the Low frequency ranges.
Anti Phase
Mid Level
0–127
Low Boost
Sw
OFF, ON Turns Low Booster on/o.
This emphasizes the bottom to
create a heavy bass sound.
Low Boost
Level
0–127 Amount of low-end boost.
Depending on the Isolator and lter
settings this eect may be hard to
distinguish.
Level 0–127 Output Level
