35 GB/IE
Check the correct positioning.
You may also connect the LED strip
3
with the 4-way divider
18
.
To do this, repeat the steps in the chapter “Trimming / connecting
the LED tape“. Please note Figure F for this purpose.
Be sure to cover the open end of the LED tape
3
with the adhe-
sive strip
20
if you do not wish to connect the end after trimming
the tape (see Fig. G).
Installing the LED strip
Note: Ensure that the installation area is clean, grease-free and dry.
Otherwise the functionality of the adhesive strip may be impaired.
Note: Ensure that a plug socket is located in close proximity to the
installation area.
Choose a suitable installation area.
Using the plug
7
, connect the mains cable
1
directly to the so-
cket
6
on the receiver
16
(see Fig. A).
Now connect the LED strip
3
with the receiver
16
. Pay attention
to the arrow marking and the polarity (+12 V DC) on the LED strip
3
(see partial view in Fig. A).
Remove the protective film from the reverse side of the LED strip
3
(see Fig. B).
Stick the LED strip
3
onto the installation area using the adhesive
strip and press it on firmly (see Fig. B).
Remove the protective film from both sides of the adhesive strip (re-
ceiver)
15
and stick this to the back of the receiver
16
(see Fig. E).
Stick the receiver
16
to the desired location.
Screw down the receiver
16
using the screws
17
.
Remove the protective film
13
from the reverse side of the cable
holder
14
(see Fig. D).
