PT‑2C – Connecting the PT‑2C
6
Configuring the PT‑2C
1. The 8-way Program DIP-switch on the rear panel is used to configure the PT‑2C according
to the following table.
Note that all the DIP-switches are set to off (up) by default.
DIP
Feature
Function
1
Lock the EDID
On (down) — EDID pass-through mode
Off (up) — EDID Locked
When EDID is locked, the audio parameters are set as defined by DIP-switch
3. In pass-through mode, the DIP-switch 3 setup is ignored
The Audio DIP-switch (3) setup is implemented only upon setting DIP-
switch 1 to off (up), locking the EDID
2
Deep color
On—Passes the deep color parameters (down)
Off—Limits deep color to 8 bits per color (up)
3
Audio setup
On—Passes the audio parameters (down)
Off—Limits the audio to 2-channel LPCM (up)
This setup is enabled only after DIP-switch 1 is set to Off (EDID locked).
4
HDCP operation
On—Passes HDCP (down)
Off—HDCP off (up)
When On, if the sink supports HDCP, the input declares HDCP support. It will
then handle HDCP on the output and input actively. If the sink does not support
HDCP then the input will not support HDCP.
When Off, the device does not support HDCP on its input, even if HDCP is
detected on the output.
5
Color space
On—Passes color space (down)
Off—Forces RGB color space (up)
6/7
Set output 5V
shutdown
6
Off
On
Off
On
7
Off
Off
On
On
Delay before 5V
output
cut-off
Always on
5s
1m
15m
The PT‑2C can power off the HDMI 5V output to let the connected device enter the sleep mode if
there is no source connected. The power off delay time is controlled by DIP-switches 6 and 7 (0 =
up/Off; 1 = down/On)
8
Reserved (always set to off)
