ENGLISH Jandy
®
X Series
™
AOP System | Installation & Operation Manual
The JAOPX500 will come with one half of a union
fi tting installed on inlet and outlet, the other half of
the fi ttings will be located in the Jandy AOP parts
bag. Use the union fi ttings provided to connect the
Jandy AOP inlet and outlet to your pool’s plumbing
as shown in Figure 3.
3.5.2 About the Mixing Degas Vessel (optional)
Under normal operations bubbles will appear in
the return fl ow to the pool. To remove the bubbles
from the fl ow, an accessory mixing degas vessel,
or MDV, can be installed downstream of the Jandy
AOP. The MDV Inline is designed for use with the
JAOPX500 and is recommended on indoor, covered,
or vinyl-lined pools. For more information, please call
Technical Support.
NOTE: An MDV Inline may be recommended to reduce
the chance of minor fading of the vinyl at the
pool’s ozone return fi tting.
Some vinyl pool liners with particular through-
wall fi ttings may be incompatible with ozone.
These fi ttings may cause fading of the vinyl liner,
* Showing the JAOPX500 and
MDV Inline (if required).
AOP*
MDV*
Filter
Heater
Check Valve
(Always install a corrosion resistant
check valve when any sanitation
equipment, including erosion feeders
and salt chlorination systems are
installed.)
Pump
Pool/Spa
3-way valve
Skimmer
Spa Return
Pool Return
Spa Drain
(suction outlet)
Main Drains
(suction outlet)
Figure 3. Typical Jandy AOP Location in Pool Plumbing Loop
cover or other vinyl components where the ozone
returns to the pool. Zodiac Pool Systems LLC is
not liable for fading of vinyl-lined pools.
3.5.3 Water Backfl ow Check Valve
If the pool equipment is mounted above the water
line, a check valve must be installed between the
pump outlet and the injector manifold to prevent the
pump from draining and losing its prime, when not in
use.
3.5.4 Pressure Test
If a pressure test is required, it should be performed
prior to installing the check valve assembly tubing
connections. See Figure 6.
1. Shut off power at the breaker.
2. Shut off water to the unit.
3. Use a fl at blade screwdriver to turn the door
latches counter clockwise and open the door.
