Page 5
Jandy
®
X Series
™
AOP System | Installation & Operation Manual ENGLISH
Section 3. Installation
3.1 Tools
• Cordless Drill
• Masonry drill bit, anchors or other appropriate
fasteners
• Wrench
3.2 Pool Preparation
To achieve optimal performance from the ozone
system, the pool must be as clean as possible to
start with.
1. Backwash or clean filters one day before
starting the ozone generator.
2. Superchlorinate pool water using a chlorine
based shock treatment so the water has a
sustained 1-3 ppm free chlorine level.
3. Test pool chemistry and adjust pH between
7.4and 7.6. Adjusttotal alkalinity between
80and 120 ppm.
4. Run pool filtration continuously for 24 hours
prior to starting ozone system.
3.3 Location
Locate the
Jandy AOP system
in a clean, protected
area, either indoorsoroutdoors (preferably out
of direct sunlight). If possible, locate the unit out
of reach of sprinklers or drainage spouts. Allow
sufficient access for maintenance (2 ft clearance
above and 1ft around the unit) and all plumbing and
electrical hookups.
3.4 Mounting
3.4.1 Floor Mounting
The Jandy AOP system is shipped with the mounting
feet installed in the floor mounting position. Adjust
the position of the feet if necessary and tighten
the screws. Mount the Jandy AOP system to the
equipment pad through the slots provided in the feet
using appropriate hardware for the mounting surface.
4X .257
(Drill Size F)
Figure 2. Wall Mounting Hole Pattern
3.4.2 Wall Mounting
The Jandy AOP unit does not have holes for wall
mounting but can be mounted on the wall if desired.
1. Drill 4 holes, (.257 in, drill size F), in the back of
the enclosure approximately as shown in Figure 2.
2. Open door as described in section Ozone
Module Servicing and clean out debris.
3. Install mounting feet in drilled holes with
hardware provided.
4. Mount unit to wall through the slots in the feet
using appropriate hardware for the mounting
surface.
3.5 Plumbing
The Jandy AOP system can easily be added into
the pool’s plumbing loop. All the components are
contained inside the enclosure so only the water inlet
and outlet need to be installed into the pool’s return
line.
3.5.1 Plumbing the JAOPX500 System
The
Jandy AOP system
must be installed in the
pool’s main return line after all other pool equipment
(pump, filter, heater, and cleaner). The outlet of the
AOP (or MDV Inline) must be at least 10 feet from the
first return to the pool. Figure 3 shows the most basic
installation. For installation with additional sanitizers
and pool cleaners, refer to Appendix A.
