Pro Series Ozone Generator
Installation Steps
1. Locate the appropriate section of the return line.
2. Observe and follow correct water ow direction (indicated by the
arrow on the injector manifold).
3. Connect the injector manifold to existing pipe with PVC cement.
Alternate Configurations
Heater
Injector
Manifold
Ozone
Generator
In-Floor
Cleaner
Pool
Sanitizer
To Spa
Water
Features
Actuator
Heater
Pool
Cleaner
Injector
Manifold
Ozone
Generator
Pool
Sanitizer
Sanitizer
Figure 6. Pool Only Alternate Equipment Configuration
Heater
Injector
Manifold
Ozone
Generator
In-Floor
Cleaner
Pool
Sanitizer
To Spa
Water
Features
Actuator
Heater
Pool
Cleaner
Injector
Manifold
Ozone
Generator
Pool
Sanitizer
Sanitizer
Figure 6. Pool/Spa Alternate Equipment Configuration
