Chapter 3 Basic Usage

The validation wizard is displayed.

4.

Set “Validation target selection”.

Item Function overview

Validation type Selecting “RGB” validates the degree of equivalence between the RGB patch

measurement values displayed on the monitor and the ICC prole values.

Selecting “CMYK” validates the degree of equivalence between the standard

values and the measurement values of the emulated CMYK patch.

Validation target Select a validation target from the pull-down menu.

Viewer Select the software to display the color patch from the pull-down menu.

Convert the measured values to

the values under D50 illuminant

Select the checkbox for using a light source other than D50 for validation.

Once the settings are complete, click .

5.

Set “Measurement device selection”.

Select a measurement device from the pull-down menu, and click .

Initialize the measurement device according to the instructions on the window. The operating method

is displayed for the measurement device. Follow the screen instructions.

Initialize the measurement device if it needs to be initialized. Initialization of a measurement device

will complete in a few seconds.

6.

When “CMYK” is selected for “Validation type”, congure the settings as

instructed on the window.

Once the settings are complete, click .

7.

Start the monitor validation.

The measurement window will be displayed. Attach the measurement device to the measurement

window. Refer to the user’s manual of the measurement device for the attachment procedure.

Pressing the “Proceed” button displays the measurement pattern and starts validation automatically.

Time until completion of the validation depends on the number of color patches.
