59
Fig. 81 — U.S. and Canada Climate Zones
Table 22 — Enthalpy Manual Entry Set Points for EconomizerONE Per Climate Zone
CLIMATE ZONES
a
NOTE(S):
a. Refer to Fig. 81 for map of U.S. and Canada climate zones.
2 TEMP OFF
LOWEST
SETTING
RH% 2 ENTH OFF RH% 2THL 2EHL RH%
1 65°F 22 Btu/lbm 43% 28 Btu/lbm 86% 83°F 33 Btu/lbm 48%
2 65°F 22 Btu/lbm 43% 28 Btu/lbm 86% 83°F 33 Btu/lbm 48%
3 65°F 22 Btu/lbm 43% 28 Btu/lbm 86% 83°F 33 Btu/lbm 48%
4 65°F 22 Btu/lbm 43% 28 Btu/lbm 86% 83°F 33 Btu/lbm 48%
5 70°F 22 Btu/lbm 28% 28 Btu/lbm 65% 83°F 33 Btu/lbm 48%
6 70°F 22 Btu/lbm 28% 28 Btu/lbm 65% 83°F 33 Btu/lbm 48%
7 and 8 75°F 22 Btu/lbm 19% 28 Btu/lbm 50% 83°F 33 Btu/lbm 48%
CALIFORNIA
TITLE 24 ZONES
b
b. Refer to Fig. 80 for map of California Title 24 zones.
2 TEMP OFF
LOWEST
SETTING
RH% 2 ENTH OFF RH% 2THL 2EHL RH%
1 75°F 22 Btu/lbm 19% 28 Btu/lbm 50% 83°F 33 Btu/lbm 48%
2 73°F 22 Btu/lbm 22% 28 Btu/lbm 55% 83°F 33 Btu/lbm 48%
3 75°F 22 Btu/lbm 19% 28 Btu/lbm 55% 83°F 33 Btu/lbm 48%
4 73°F 22 Btu/lbm 22% 28 Btu/lbm 55% 83°F 33 Btu/lbm 48%
5 75°F 22 Btu/lbm 19% 28 Btu/lbm 50% 83°F 33 Btu/lbm 48%
6 71°F 22 Btu/lbm 28% 28 Btu/lbm 62% 83°F 33 Btu/lbm 48%
7 69°F 22 Btu/lbm 32% 28 Btu/lbm 68% 83°F 33 Btu/lbm 48%
8 71°F 22 Btu/lbm 28% 28 Btu/lbm 62% 83°F 33 Btu/lbm 48%
9 71°F 22 Btu/lbm 28% 28 Btu/lbm 62% 83°F 33 Btu/lbm 48%
10 73°F 22 Btu/lbm 22% 28 Btu/lbm 55% 83°F 33 Btu/lbm 48%
11 75°F 22 Btu/lbm 19% 28 Btu/lbm 50% 83°F 33 Btu/lbm 48%
12 75°F 22 Btu/lbm 19% 28 Btu/lbm 50% 83°F 33 Btu/lbm 48%
13 75°F 22 Btu/lbm 19% 28 Btu/lbm 50% 83°F 33 Btu/lbm 48%
14 75°F 22 Btu/lbm 19% 28 Btu/lbm 50% 83°F 33 Btu/lbm 48%
15 75°F 22 Btu/lbm 19% 28 Btu/lbm 50% 83°F 33 Btu/lbm 48%
16 75°F 22 Btu/lbm 19% 28 Btu/lbm 50% 83°F 33 Btu/lbm 48%
CONTROLLER
DEFAULT SETTINGS
2 TEMP OFF — — 2 ENTH OFF — 2THL 2EHL RH%
DEFAULT
SET POINTS
63°F — — 28 Btu/lbm 94% 83°F 33 Btu/lbm 48%
Climate Zone 1
Climate Zone 2
Climate Zone 3
Climate Zone 4 (Except Marine)
Climate Zone 5 and Marine
Climate Zone 6
Climate Zone 7 and 8
U.S. and Canada I-Codes / ASHRAE Zones
