Table 16 — Parameter Settings — Advanced
PARAMETER DESCRIPTION VALUE/RANGE DEFAULT
3FREEZE POS Anti-freeze protection damper position (closed or minimum).
CLO
MIN
CLO
3SD ACT POS Damper position during shutdown (open or closed).
CLO
OPN
CLO
3DIF T LOC
MAT sensor location:
• Choose MAT if the sensor is installed before the DX (Direct Expansion) coil.
• Choose LAT if the sensor is installed after the DX coil.
• Choose AUTO to let the Economizer Controller automatically detect the
location.
MAT
LAT
AUTO
LAT
3LAT LOW
Low limit of leaving air temperature.
Dynamic item: Appears only if LAT or AUTO is selected for 3DIF T LOC.
35...65°F; increment by 1 45°F
3LAT HIGH
High limit of leaving air temperature.
Dynamic item: Appears only if LAT or AUTO is selected for 3DIF T LOC.
70...180°F; increment by 1 80°F
3OAT CAL OAT sensor calibration.
–2.5...2.5°F; increment by
0.5
0°F
3RAT CAL
RAT sensor calibration.
Dynamic item: Appears only if an RAT sensor is configured.
–2.5...2.5°F; increment by
0.5
—
3OAH CAL
OAH sensor calibration.
Dynamic item: Appears only if an OAH sensor is configured.
–10...10%; increment by 0.5 0%
3RAH CAL
RAH sensor calibration.
Dynamic item: Appears only if an RAH sensor is configured.
3MAT CAL MAT or LAT sensor calibration.
–2.5...2.5°F; increment by
0.5
0°F
3MAT SET Set point of MAT or LAT sensor. 38...70°F; increment by 1 53°F
3FRZ PROT Anti-freeze protection set point of MAT sensor. 35...55°F; increment by 1 45°F
3ACT TOLR
Actuator tolerance setpoint between output (in percent) and feedback (in
percent).
0...15%; increment by 1 8%
3OAT LOCK OAT lockout set point for anti-freeze protection. –45...80°F; increment by 1 32°F
3OAT LCKOVRD
When OAT LOCKOUT is enabled, choose to override the cooling lockout
function or not.
YES
NO
NO
3OAT LOCKODLY Indicates the overridden time if “YES” is selected for “
3OAT LCKOVRD”. 0...300 min; increment by 1 45 min.
Table 17 — Parameter Settings — I/O Configurations
PARAMETER DESCRIPTION VALUE DEFAULT
6OCC
Configures if occupancy status receives signal from the connected thermostat or
is displayed as ALWAYS in the Economizer Controller.
T-STAT
ALWAYS
T-STAT
6AUX1-I
Auxiliary DI-1. Configurable as:
• None.
• Heat Conventional (W1) from thermostat.
• Heat pump (reversing valve O).
• Heat pump (reversing valve B).
• Pre-occupancy signal from thermostat.
• Shutdown signal from unit.
NONE
HP(O)
HP(B)
PREOCC
SHUTDWN
W1
6AUX2-I
Auxiliary DI-2. Configurable as:
• None.
• Heat stage 1 (W1) from thermostat.
• Heat pump (reversing valve O).
• Heat pump (reversing valve B).
• Pre-occupancy signal from thermostat.
• Shutdown signal from unit.
NOTE: Whichever is chosen for 6AUX1-I does not appear in the list of 6AUX2-I.
NONE
W1
HP(O)
HP(B)
PREOCC
SHUTDWN
NONE
6OAT SIG Configures signal type of OAT sensor.
0-10V
NTC10K
NTC10K
6RAT SIG Configures signal type of RAT sensor.
0-10V
NTC10K
NONE
NONE
6OAH SIG Configures signal type of OAH sensor. 0-10V
4-20mA
NONE
NONE
6RAH SIG Configures signal type of RAH sensor.
6MAT SIG Configures signal type of MAT or LAT sensor.
0-10V
NTC10K
NTC10K
6AUX-AI1
Auxiliary AI-1. Configurable as:
•CO
2
sensor.
• Static pressure (temporarily for CFM commissioning) sensor.
• None.
PRESSURE
CO2
NONE
NONE
6X-AI1 SIG
Configures CO2 sensor type.
Dynamic item: Appears only if “CO2” is selected for “6AUX-AI1”.
0-10V
2-10V
0-5V
0-10V
6CO2 Rng L
Configures the low limit of CO2 measuring range.
Dynamic item: Appears only if “CO2” is selected for “6AUX-AI1”.
0...500; increment by 10 0
6C02 Rng H
Configures the high limit of CO2 measuring range.
Dynamic item: Appears only if “CO2” is selected for “6AUX-AI1”.
1000...3000;
increment by 50
2000
