52
SETUP AND CONFIGURATION
Set up and configure the economizer controller before putting
it into usage. This can be accomplished by using the Climatix
™
mobile application or the inbuilt display. After sensor, com-
pressor, thermostat, or actuator is connected to the economizer
controller, values/statuses are displayed in the Operating sec-
tion of the mobile application and on the LCD. Users can man-
ually change basic and advanced settings, configure I/Os, and
test the damper operation and any configured outputs by modi-
fying the corresponding parameter values in the local device or
mobile application. See Tables 14-21 for a complete list of all
parameters that users can find on the LCD display. Refer to it
during the setup and configuration process.
NOTE: For all units, the Climatix application login is:
Administrator. For units coming from the factory with CO
2
con-
figuration or single enthalpy (control mode 3), the controller pass-
word is OneBT2.1. For all other units, use the controller password
OneBT.
NOTE: Parameters and display menus may display
differently/dynamically if different applications are config-
ured. See Tables 14-21.
IMPORTANT: Before setup and configuration, it is recom-
mended to obtain some location-based values, such as shutoff
points, or utilize the location services in the Climatix
™
mobile
application.
IMPORTANT: Not all operations are available on the local
POL 224. For example, users can only obtain shutoff set
points and perform cfm commissioning via the Climatix
™
mobile application. Setup and configuration on the local
device are only recommended if operations from the mobile
application are unavailable. Check the mobile application for
all operations that can be performed from the mobile
application end.
IMPORTANT: By connecting the RS485 port to a PC, all
parameters are also readable or writable from PC tools such
as Modbus Poll.exe via Modbus
®a
and Yabe.exe via
BACnet
™a
MSTP (Bps 38400 [default], Bps 9600, Bps
19200, Bps 115200). Note that an external End of Line (EOL)
element is required to achieve Baud Rate 115200 at a
maximum cable length of 4000 ft (1.2 km).
NOTE(S):
a. Third-party trademarks and logos are the property of their respective owners.
