Table 2 — Physical Data — 50WD 030-070 Units
UNIT SIZE 030 036 042 048 060 070
Compressor Type (Qty 1) Scroll Scroll Scroll Scroll Scroll Scroll
Max Water Working Pressure
(psig)
a
400 400 400 400 400 400
ECM FAN MOTOR and BLOWER
Fan Motor Type Constant Airflow Constant Airflow Constant Airflow Constant Airflow Constant Airflow Constant Airflow
Fan Motor (hp) 0.50 0.75 0.75 0.75 1.00 1.00
Blower Wheel Size (in.) (Dia. x W) 10 x 8 10 x 8 10 x 8 10 x 8 12 x 9 12 x 9
WATER CONNECTION SIZE (includes Economizer option)
FPT (in.) 0.75 0.75 0.75 1.00 1.00 1.00
Coaxial Coil Volume (gal) 0.28 0.28 0.38 0.46 0.46 0.46
VERTICAL CABINET
Refrigeration Charge (oz) 32.0 35.0 42.0 48.0 80.0 57.5
Air Coil Dimensions (in.) (H x W) 19 x 16.5 28 x 21 28 x 21 28 x 21 36 x 27 36 x 27
Standard Filter - 1" Throwaway
(L x H)
19 x 27 24 x 30 24 x 30 24 x 30 18 x 30 (2) 18 x 30 (2)
Optional Filter - 2" MERV 8 or 13
(L x H)
19 x 27 24 x 30 24 x 30 24 x 30 18 x 30 (2) 18 x 30 (2)
Optional Filter - 4" MERV 13 (L x H) 19 x 27 24 x 30 24 x 30 24 x 30 18 x 30 (2) 18 x 30 (2)
Weight - Operating (lb) 212 233 271 276 347 323
Weight - Shipping (lb) 238 259 297 301 371 347
HORIZONTAL CABINET
Refrigeration Charge (oz) 31.0 32.0 46.0 48.0 67.5 54.5
Air Coil Dimensions (in.) (H x W) 16 x 27.5 16 x 27.5 18 x 31 18 x 31 20 x 42 20 x 45
Standard Filter - 1" Throwaway
(L x H)
18 x 30 18 x 30 20 x 34 20 x 34
20 x 20
and 20 x 24
20 x 24 (2)
Optional Filter - 2" MERV 8 or 13
(L x H)
18 x 30 18 x 30 20 x 34 20 x 34
20 x 20 and
20 x 24
20 x 24 (2)
Optional Filter - 4" MERV 13 (L x H) 18 x 30 18 x 30 20 x 34 20 x 34
20 x 20
and 20 x 24
20 x 24 (2)
Weight - Operating (lb) 204 205 281 292 319 321
Weight - Shipping (lb) 231 232 307 317 343 345
NOTE(S):
a. 300 psig when unit is built with the factory installed 2-way solenoid valve option.
LEGEND
FPT — Female Pipe Thread
