Table 30 — 50WD042 Typical Unit Operating Pressures and Temperatures
ENTER FLUID
TEMP
(°F)
COOLING HEATING
Water Flow
(gpm/ton)
Suction
Pressure
(psig)
Discharge
Pressure
(psig)
Water Temp
Rise
(°F)
Air Temp
Drop
(°F)
Suction
Pressure
(psig)
Discharge
Pressure
(psig)
Water Temp
Rise
(°F)
Air Temp
Drop
(°F)
30
6.0 — — — — 55-65 255-279 7-8 19-23
10.5 — — — — 60-70 260-284 4-5 20-24
40
6.0 109-125 202-226 17-20 22-26 67-77 268-292 8-9 21-25
10.5 107-123 173-197 10-13 22-26 73-83 275-299 5-6 23-27
50
6.0 110-126 229-253 17-20 21-25 80-90 282-306 10-11 24-28
10.5 109-125 199-223 9-12 22-26 88-98 291-315 6-7 26-30
60
6.0 112-128 258-282 16-19 21-25 94-104 298-322 11-12 27-31
10.5 110-126 228-252 9-12 21-25 104-114 310-334 7-8 30-34
70
6.0 113-129 291-315 16-19 21-25 143-153 353-377 1-2 37-41
10.5 112-128 260-284 9-12 21-25 123-133 330-354 8-9 33-37
80
6.0 115-131 328-352 15-18 20-24 128-138 336-360 14-15 34-38
10.5 114-130 296-320 9-12 21-25 143-153 353-377 9-10 37-41
90
6.0 117-133 368-392 15-18 20-24 148-158 358-382 16-17 38-42
10.5 115-131 337-361 8-11 20-24 166-176 378-402 9-10 42-46
100
6.0 118-134 411-435 14-17 19-23 — — — —
10.5 117-133 381-405 8-11 20-24 — — — —
Table 31 — 50WD048 Typical Unit Operating Pressures and Temperatures
ENTER FLUID
TEMP
(°F)
WATER
FLOW
(gpm/ton)
COOLING HEATING
Suction
Pressure
(psig)
Discharge
Pressure
(psig)
Water Temp
Rise
(°F)
Air Temp
Drop
(°F)
Suction
Pressure
(psig)
Discharge
Pressure
(psig)
Water Temp
Rise
(°F)
Air Temp
Drop
(°F)
30
8 — — — — 54-74 268-288 6-7 20-24
12 — — — — 57-77 272-292 4-5 20-24
40
8 105-121 183-203 14-17 21-25 67-87 283-303 8-9 23-27
12 104-120 169-189 9-12 22-26 71-91 288-308 5-6 24-28
50
8 106-122 210-230 14-17 21-25 81-101 300-320 9-10 26-30
12 106-122 196-216 9-12 21-25 86-106 306-326 6-7 27-31
60
8 108-124 241-261 14-17 21-25 97-117 319-339 10-11 29-33
12 108-124 227-247 9-12 21-25 104-124 327-347 7-8 31-35
70
8 110-126 275-295 13-16 20-24 115-135 340-360 11-12 33-37
12 109-125 261-281 9-12 20-24 123-143 350-370 8-9 35-39
80
8 112-128 313-333 13-16 20-24 134-154 364-384 13-14 37-41
12 111-127 300-320 8-11 20-24 145-165 376-396 9-10 39-43
90
8 113-129 354-374 12-15 19-23 156-176 390-410 14-15 41-45
12 113-129 342-362 8-11 20-24 169-189 404-424 10-11 43-47
100
8 115-131 399-419 12-15 19-23 — — — —
12 115-131 388-408 8-11 19-23 — — — —
