Table 18 — 50WD Horizontal Units — Constant Airflow Motor Performance
a,b,c
MODEL FAN SPEED
DEFAULT
FACTORY
MOTOR
SETTING
AIRFLOW (cfm) AT EXTERNAL STATIC PRESSURE (in. wg)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20
015
A - 425 425 425 425 425 425 425 425 — — — —
A Norm X 500 500 500 500 500 500 500 500 — — — —
A + 575 575 575 575 575 575 575 575 — — — —
018
A - 510 510 510 510 510 510 510 510 — — — —
A Norm X 600 600 600 600 600 600 600 600 — — — —
A + 700 700 700 700 700 700 700 700 — — — —
024
Full Load
A - 680 680 680 680 680 680 680 680 — — — —
A Norm X 800 800 800 800 800 800 800 800 — — — —
A + 920 920 920 920 920 920 920 920 — — — —
024
Part Load
A - 510 510 510 510 510 510 510 510 — — — —
A Norm X 600 600 600 600 600 600 600 600 — — — —
A + 690 690 690 690 690 690 690 690 — — — —
03
Full Load
A - 810 810 810 810 810 810 810 810 — — — —
A Norm X 950 950 950 950 950 950 950 950 — — — —
A + 1100 1100 1100 1100 1100 1100 1100 1100 — — — —
03
Part Load
A - 640 640 640 640 640 640 640 640 — — — —
A Norm X 750 750 750 750 750 750 750 750 — — — —
A + 860 860 860 860 860 860 860 860 — — — —
036
Full Load
A - 1020 1020 1020 1020 1020 1020 1020 1020 1020 1020 — —
A Norm X 1200 1200 1200 1200 1200 1200 1200 1200 1200 1200 — —
A + 1380 1380 1380 1380 1380 1380 1380 1380 1380 1380 — —
036
Part Load
A - 765 765 765 765 765 765 765 765 765 765 — —
A Norm X 900 900 900 900 900 900 900 900 900 900 — —
A + 1035 1035 1035 1035 1035 1035 1035 1035 1035 1035 — —
042
Fill Load
A - 1230 1230 1230 1230 1230 1230 1230 1230 1230 1230 — —
A Norm X 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400 — —
A + 1610 1610 1610 1610 1610 1610 1610 1610 1610 1610 — —
042
Part Load
A - 970 970 970 970 970 970 970 970 970 970 — —
A Norm X 1120 1120 1120 1120 1120 1120 1120 1120 1120 1120 — —
A + 1310 1310 1310 1310 1310 1310 1310 1310 1310 1310 — —
048
Full Load
A - 1360 1360 1360 1360 1360 1360 1360 1360 1360 1360 — —
A Norm X 1600 1600 1600 1600 1600 1600 1600 1600 1600 1600 — —
A + 1840 1840 1840 1840 1840 1840 1840 1840 1840 1840 — —
048
Part Load
A - 1020 1020 1020 1020 1020 1020 1020 1020 1020 1020 — —
A Norm X 1200 1200 1200 1200 1200 1200 1200 1200 1200 1200 — —
A + 1380 1380 1380 1380 1380 1380 1380 1380 1380 1380 — —
060
Full Load
A - 1700 1700 1700 1700 1700 1700 1700 1700 1700 1700 1700 1700
A Norm X 2000 2000 2000 2000 2000 2000 2000 2000 2000 2000 2000 2000
A + 2300 2300 2300 2300 2300 2300 2300 2300 2300 2300 2300 2300
060
Part Load
A - 1275 1275 1275 1275 1275 1275 1275 1275 1275 1275 1275 1275
A Norm X 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500 1500
A + 1725 1725 1725 1725 1725 1725 1725 1725 1725 1725 1725 1725
070
Full Load
A - 1785 1785 1785 1785 1785 1785 1785 1785 1785 1785 1785 1785
A Norm X 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100 2100
A + 2415 2415 2415 2415 2415 2415 2415 2415 2415 2415 2415 2415
070
Part Load
A - 1403 1403 1403 1403 1403 1403 1403 1403 1403 1403 1403 1403
A Norm X 1650 1650 1650 1650 1650 1650 1650 1650 1650 1650 1650 1650
A + 1898 1898 1898 1898 1898 1898 1898 1898 1898 1898 1898 1898
NOTE(S):
a. During fan only operation air flow is 70% of tabulated value.
b. When passive dehumidification mode is enabled, air flow is 85% of tabulated value.
c. Cfm airflow is based on wet coil and 1 in. disposable MERV 5 filter.
LEGEND
PL — Part Load
FL — Full Load
