LEGEND
Table 20 — Electric Heater Data – 208/230-3-60 and 240-3-60
UNIT
SIZE
39L
HEATER
AREA
(sq ft)
NO. OF
CONTROL
STEPS
a
NOTE(S):
a. Subcircuits are internal heater circuits of 48 amps or less.
HEATER
COIL
kW
NOMINAL
COIL FACE
VELOCITY
(fpm)
TEMP
RISE
(°F)
208-3-60 v-ph-Hz 240-3-60 v-ph-Hz
Total
FLA
MCA
b
b. Electric heat performance is not within the scope of AHRI standard 430 certification.
No.
Sub-
Ckt
MOCP
Total
FLA
MCA
b
No.
Sub-
Ckt
MOCP
03 2.2 3
9.0 500 26 25 31 1 35 22 27 1 30
15.0 500 44 42 52 1 60 36 45 1 50
17.2 500 50 48 60 1 60 41 52 1 60
06 3.7 6
8.0 500 14 22 28 1 30 19 24 1 25
10.0 500 17 28 35 1 35 24 30 1 35
17.0 500 29 47 59 1 60 41 51 1 60
19.9 500 34 55 69 2 70 48 60 1 60
27.0 500 47 75 94 2 100 65 81 2 90
29.8 500 51 83 104 2 110 72 90 2 90
36.0 500 62 100 125 3
c
c. To avoid damage due to overheating, minimum face velocity cannot fall below 350 fpm.
150 87 108 2 110
08 5.1 6
15.0 500 19 42 52 1 60 36 45 1 50
25.0 500 31 69 87 2 90 60 75 2 80
35.0 500 44 97 122 3 125 84 105 2 110
39.9 500 50 111 139 3 150 96 120 3 125
43.2 500 54 120 150 3 175 104 130 3 150
51.0 500 64 142 177 3 200 123 154 3 175
10 6.2 6
15.0 500 15 42 52 1 60 36 45 1 50
25.0 500 26 69 87 2 90 60 75 2 80
39.9 500 41 111 139 3 150 96 120 3 125
47.3 500 49 131 164 3 175 114 142 3 150
51.8 500 53 144 180 3 200 125 156 3 175
59.8 500 62 — — — — — — — —
12 7.3 6
19.9 500 17 55 69 2 70 48 60 1 60
29.8 500 26 83 104 2 110 72 90 2 90
39.9 500 35 111 139 3 150 96 120 3 125
43.0 500 38 119 149 3 150 104 129 3 150
51.8 500 45 144 180 3 200 125 156 3 175
72.0 500 63 — — — — — — — —
15 10.0 6
19.9 500 13 55 69 2 70 48 60 1 60
29.8 500 19 83 104 2 110 72 90 2 90
39.9 500 25 111 139 3 150 96 120 3 125
45.0 500 29 125 156 3 175 108 135 3 150
51.8 500 33 144 180 3 200 125 156 3 175
65.0 500 42 — — — — — — — —
86.0 500 55 — — — — — — — —
18 11.74 6
19.9 500 11 55 69 2 70 48 60 1 60
25.8 500 14 72 90 2 90 62 78 2 80
35.0 500 19 97 122 3 125 84 105 2 110
45.0 500 25 125 156 3 175 108 135 3 150
51.8 500 28 144 180 3 200 125 156 3 175
78.0 500 43 — — — — — — — —
94.0 500 51 — — — — — — — —
21 14.21 6
19.9 500 9 55 69 2 70 48 60 1 60
25.8 500 12 72 90 2 90 62 78 2 80
35.0 500 16 97 122 3 125 84 105 2 110
45.0 500 20 125 156 3 175 108 135 3 150
51.8 500 23 144 180 3 200 125 156 3 175
79.8 500 36 — — — — — — — —
92.0 500 41 — — — — — — — —
116.0 500 52 — — — — — — — —
25 17.79 6
30.0 500 11 83 104 2 110 72 90 2 100
39.9 500 14 111 139 3 150 96 120 3 125
50.0 500 18 139 174 3 175 120 151 3 175
65.0 500 23 181 226 4 250 157 196 4 200
79.8 500 29 222 277 5 300 192 240 5 250
96.5 500 35 268 335 6 350 232 291 5 300
110.0 500 39 — — — — 265 331 6 350
145.0 500 52 — — — — — — — —
AHRI — Air Conditioning, Heating and Refrigeration Institute
FLA — Full Load Amps
kW — Kilowatts
MCA — Minimum Circuit Amps
MOCP — Maximum Overcurrent Protection
