AFE1 Emergency stop (off2)
Drive has received an
emergency stop (mode
selection off2) command.
Check that it is safe to continue operation. Then return
emergency stop push button to normal position. Restart drive.
If the emergency stop was unintentional, check the source
selected by parameter 21.05 Emergency stop source.
AFE2
Emergency stop (off1 or
off3)
Drive has received an
emergency stop (mode
selection off1 or off3)
command.
Check that it is safe to continue operation. Then return
emergency stop push button to normal position. Restart drive.
If the emergency stop was unintentional, check the source
selected by parameter 21.05 Emergency stop source.
Informative warning. See parameter 21.22 Start delay.
AFE9 Start delay
The start delay is active and
the drive will start the motor
after a predefined delay.
Check that it is safe to continue operation. Then return
emergency stop push button to normal position. Restart drive.
If the emergency stop was unintentional, check the source
selected by parameter 21.05 Emergency stop source.
Informative warning. See parameter 21.22 Start delay.
AFED Run permissive
Run permissive is keeping
the drive from running the
motor.
Check the setting of (and source selected by) parameter 20.40
Run permissive.
AFEE Start interlock 1
Start interlock 1 is keeping
the drive from starting.
Check the signal source selected for parameter 20.41 Start
interlock 1.
AFEF Start interlock 2
Start interlock 2 is keeping
the drive from starting.
Check the signal source selected for parameter 20.42 Start
interlock 2.
AFF0 Start interlock 3
Start interlock 3 is keeping
the drive from starting.
Check the signal source selected for parameter 20.43 Start
interlock 3.
AFF1 Start interlock 4
Start interlock 4 is keeping
the drive from starting.
Check the signal source selected for parameter 20.44 Start
interlock 4.
AFF2
Run permissive forced
warning
A forced DI is used as a
source for parameter 20.40
Run permissive.
If 20.40 Run permissive uses DIx as the source, check if the bit
corresponding to DIx in parameter 10.03 DI force selection is 1.
AFF3
Start interlock forced
warning
One or more forced DIs is
used as a source for one or
more of parameters
20.41
Start interlock 1. 20.44 Start
interlock 4.
Check all parameters 20.41 Start interlock 1 ... 20.44 Start
interlock 4. If any of these parameters uses DIx as the source,
check if the bit corresponding to DIx in parameter 10.03 DI force
selection is 1.
AFF5 Override new start required
The Safe torque off function
was active and has been
reset while in Override.
A new start signal is required to start the drive again.
AFF6 Identification run
Motor ID run will occur at
next start.
Informative warning.
AFF8 Motor heating active
Pre-heating is being
performed
Informative warning.
Motor pre-heating is active. Current specified by parameter
21.16 Preheating current is being passed through the motor.
AFFE Override active Drive is in Override mode. Informative warning.
B5A2 Power applied
The drive was powered up or
the control board was
rebooted successfully.
Informative event.
B681 Hand mode selected
The drive was placed in
Hand mode.
Informative event. Check the control panel to ensure that the
current control location is correct.
B682 Off mode selected
The drive was placed in Off
mode.
Informative event. Check the control panel to ensure that the
current control location is correct.
B683 Auto mode selected
The drive was placed in Auto
mode.
Informative event. Check the control panel to ensure that the
current control location is correct.
2310 Overcurrent
Output current has exceeded
internal fault limit.
Check motor load.
In addition to an actual
overcurrent situation, this
fault may also be caused by
an earth fault or supply
phase loss.
Check acceleration times in parameter group 23 Speed
reference ramp (speed control) or 28 Frequency reference chain
(frequency control). Also check parameters 46.01 Speed scaling,
46.02 Frequency scaling and 46.03 Torque scaling.
Check motor and motor cable (including phasing and delta/star
connection). Check there are no contactors opening and closing
in motor cable.
Check that the start-up data in parameter group 99 corresponds
to the motor rating plate.
Check that there are no power factor correction capacitors or
surge absorbers in motor cable.
Check for an earth fault in motor or motor cables by measuring
the insulation resistances of motor and motor cable. See chapter
Electrical installation, section Checking the insulation of the
assembly in the Hardware manual
of the drive.
Table 8 — Fault and Alarm Codes for ACH580 VFD (cont)
