4
For the steps below, the LED located inside the interface can only be seen while active. The
interface does not need to be opened to see the LED
• Start the vehicle.
• Connect the AXDIS-HK2 harness to the wiring harness in the vehicle.
• The LED will initially turn on solid Green, then turn off for a few seconds while it auto
detects the radio installed.
• The LED will then flash Red up to (24) times indicating which radio is connected to the
interface, and then turn off for a couple of seconds. Pay close attention to how many
Red flashes there are. This will help in troubleshooting, if need be. Refer to the LED
feedback section for more information.
• After a couple seconds the LED will turn on solid Red while the interface auto detects the
vehicle. The radio will shut off at this point. This process should take 5 to 30 seconds.
• Once the vehicle has been auto detected by the interface, the LED will turn on solid Green,
and the radio will come back on, indicating programming was successful.
• Test all functions of the installation for proper operation, before reassembling the dash.
• If the interface fails to function, refer to Resetting the AXDIS-HK2.
Note:
The LED will turn on solid Green for a moment, and then turn off under normal
operation after the key has been cycled.
PROGRAMMING THE AXDIS-HK2
With the key in the off position:
• Connect the 16-pin harness with stripped leads, and the AXDIS-HK2 harness, into the
interface.
• For models equipped with a factory amplifier, connect the AXSP-HK (sold separately) to
the interface.
Attention!
Do not connect the AXDIS-HK2 harness
harness to the wiring harness in the vehicle just yet.
Attention!
If retaining steering wheel controls, ensure that the jack/wire is connected to the
radio before proceeding. If this step is skipped, the interface will need to be reset for the steering
wheel controls to function.
INSTALLING THE AXDIS-HK2
