Input Select Switches

1. These 3-position switches allow you to choose the internal signal routing for each channel pair’s output stage. They offer options for 2-channel, 4-channel, or 6-channel input, as well

as different configurations for independent and summed inputs.

a. The CH3/4 and CH5/6 Input Select switches determine how the signals are routed for each channel pair’s output stage. They provide options for 2-channel, 4-channel, or

6-channel input, as well as different independent and summed input configurations.

b. Copy: The bottom switch position copies the signal from the previous channel pair without adjusting the gain, and routes it to the outputs. To have independent gain control,

use jumper wires at the speaker input terminals and select direct input instead.

c. Direct: The middle switch position directly routes the channel pair’s input signal to its gain and output stages.

d. Sum: The upper switch position combines the indicated channel signals after their respective gain stages and sends the combined signals to the left and right RCA outputs

Factory radios and amplifiers can sometimes stop passing audio when they do not see the original speaker’s impedance. This is a common issue found in many Chrysler vehicles. The

Axxess Load Resistors (sold separately) offer different resistor values that will make the factory equipment think the original speakers are still connected and starts passing audio. In some

Chrysler vehicles you will need to let the vehicle go the sleep (turn ignition off for 2 minutes) after each load selection.

AX-LR20 (20

) – Commonly used in vehicles that do not have a factory amplifier. Mainly late model Chrysler vehicles, which includes RAM, JEEP, DODGE, and some FIATS

AX-LR39 (39

) – Used in factory systems that mute or cause distortion when replacing OEM speakers

AX-LR60 (60

) – Commonly used in vehicles with a factory amplifier. Mainly late model Chrysler vehicles, which includes RAM, JEEP, DODGE, and some FIATS

INPUT/OUTPUT SETTING SWITCHES
