H0439100.A1.EN–2013/10
4
2.3Installingthedevice
placeonastable,solid(concreteslabtype),levelandplanesurface,
ensurethatitwillnotbefloodedbycondensationwaterproducedbythedeviceduringoperation(see§2.4)
Theanti‐vibrationblocsarefittedunderthebaseoftheheatpump.
The heat pump can befixedtothe ground using the brackets at the base of the unit (attachments not
included).Adiagramfordrillingisfeaturedonthebackofthepackingbox.
2.4Hydraulicconnections
Checkthedirectionofthepipeworkconnection(see§“Dimensions”intheappendix).
TheconnectionincludeaØ50PVCrigidpipe,fromaby‐pass,ontheswimmingpoolfiltrationcircuit,afterthe
filterandbeforeanywatertreatmentunit.
checkthetighteningofthehydraulicconnections,andcheckforleaks,
Z300
Hydrauliccircuitpressure Connections
=inlet
=outlet
Meanwater
flowrate
Headloss
test
test service
bar bar m³/h mCE
M4
3 1.5 Ø50
4 1.4
M5‐T5‐
MD5‐TD5
5 1.5
M7 6 1.5
MD8‐TD8 6.5 1.1
V1‐V2‐V3:by‐passvalves
V5‐V4:settingvalves(optional)
*minimumdistance
by‐pass
filter
watertreatmentunit
electricalprotectionboxes
Fixingholes
