H0439100.A1.EN–2013/10
3
1.3Operatingconditions
Operatingrange:
airtemperatureofbetween5°Cand38°Cforstandardmodels,
airtemperatureofbetween‐8°Cand38°CforDmodels,
watertemperatureofbetween10°Cand32°C,
Maximumtemperatureof 32°Ctoprotectthepoolliner.
TheDversionalsofeaturesade‐icingfunctionbyusingforcedventilationorreversedcycle.
1.4Technicalspecifications
Z300 Voltage
Powerinput* Poweroutput* Nominalcurrentinput*
COP*
kW kW A
M4 230V‐50Hz 1.7 7.6 7.9 4.5
M5 230V‐50Hz 2.2 10.4 10.3 4.7
T5 400V‐50Hz 2.2 10.5 4.25 4.8
M7 230V‐50Hz 2.88 13.9 13 4.8
MD5 230V‐50Hz 2.2 10.7 10 4.9
TD5 400V‐50Hz 2.2 10.5 4.4 4.8
MD8 230V‐50Hz 3.6 15.7 16 4.5
TD8 400V‐50Hz 3.6 15.7 7.4 4.5
*withambientairat+15°C,poolwaterat26°C,andrelativehumidityof70%(accordingtoFrenchstandardNF‐
414)
protectionclass:IP24
refrigerantgas:R410A
refrigerantcharge:seeproductinformationplate
class:I,
degreeofpollution:2,
overvoltagecategory:II
2.Installation
Donottakegripontheoutercasingtopickupthedevice,holdthebase.
2.1Accesstothetechnicalcompartment
2.2Selectinganinstallationsite
The device must be installed outdoors and there must be adequate open space surrounding it (see
§2.4).
theheatpumpmustbeinstalledatacertaindistancefromthepoolsoastoavoidexposuretowatersplashes.
The appropri ate distance should be defined according to the national electrical standards that apply in the
countryofinstallation(forFrance: 3.5meters).
theheatpumpmustnotbeinstalled:
- nearasourceofheatorinflammablega
s,
- neararoad/passagewherethereisariskofwaterandmudsplashes,
- facingastrongwind,
- with theventfacingtowarda permanentor tem porary obstacle (window, wall, hedge, etc…), it must be at
least4metersfromanypo
tentialobstacle.
