Display Designation Cause Solution Reset
Refrigerant
circuitlow
pressuredefect
Lowpressurecircuit
pressuredefect(if
thedefectremains
afterreset)
Contactanapproved
technician
Automaticreset
(forlessthan4
defectsperhour)
orpress
Refrigerant
circuithigh
pressuredefect
1.waterandair
mixturepassingin
theappliance,
2.unsatisfactory
waterflow,
3.blockedflow
controller
4.cloggedorblocked
heatexchanger
1.checkthepoolhydraulic
circuit
2.increasetheflow‐rate
usingtheby‐pass,checkthat
thepoolfilterisnotclogged)
3.checktheflow‐rate
controller
4.cleantheexchanger
5.ifthedefectpersists,
contactanapproved
technician
Automaticreset
(forlessthan4
defectsperhour)
orpress
Compressor
discharge
temperature
defect
Compressor
discharge
temperaturetoo
high
contactanapproved
technician
pressfor3
seconds
Controlsensor
defect(ST1)
Sensorout‐of‐order
ordisconnected
(connectorJ2redon
plateA1)
Replaceorreconnectthe
sensor
Switchthepower
supplyoffor
press
Waterflow‐rate
sensordefect
(ST4)
Sensorout‐of‐order
ordisconnected
(connectorJ8white
onplateA1)
Replaceorreconnectthe
sensor
Switchthepower
supplyoffor
automaticresetif
thedefect
disappears
Defrostsensor
defect(ST3)
Sensorout‐of‐order
ordisconnected
(terminals1‐2of
connectorJ3white
onplateA2)
Replaceorreconnectthe
sensor
Switchthepower
supplyoffor
press
Anti‐freeze
sensordefect
(ST2)
Sensorout‐of‐order
ordisconnected
(terminals
3‐4ofconnectorJ3
whiteonplateA2)
Replaceorreconnectthe
sensor
Switchthepower
supplyoffor
press
Compressor
discharge
sensordefect
(ST5)
Sensorout‐of‐order
ordisconnected
(connectorJ7black
onplateA1)
Replaceorreconnectthe
sensor
Switchthepower
supplyoffor
automaticresetif
thedefect
disappears.
Communication
s'defect
betweenthe
maincardA1
andthedisplay
cardA2
1.Incorrect
connectionbetween
platesA1andA2
2.Cardsupplydefect
3.Cardsoutoforder
1and2.Checkconnections
(connectorsJ8andJ9yellow,
andJ7andJ4‐J5black)
1,2and3.ifthedefect
persists,cont
actan
approvedte
chnician
Switchthepower
supplyoffor
automaticresetif
thedefect
disappears
