Je bekijkt pagina 11 van 22
H0439100.A1.EN–2013/10
10
4.2.2Troubleshooting
allsolderingworkmustbecarriedoutbyasomeonequalifiedtodoso.
replacementpipesmustalwaysbemadeofcopperincompliancewithstandardNFEN12735‐1.
leakdetection;pressuretest:
- neveruseoxygenordryair,riskoffireorexplosion,
- usedrynitrogenorthemixtureofnitrogenandrefrigerantindicatedontheinformationplate,
- thetestpressureforboththehighandlowpressurecircuitsmustnotexceed42bar.
the high pressure circuit pipes are made of copper and have a diameter equal to or greater than 1’’5/8. A
certificateas
indicatedin§2.1incompliancewithstandardNFEN10204will berequestedfromthesupplierand
filedininstallationtechnicaldocumentation.
technicaldatarelativetothesafetyrequirementsofthevariousapplicabledirectivesmustbeindicatedonthe
informationplate.
Thisdatamustberecorde
dinthein
stallationinstructionsforthedevicewhichareincludedintheinstallation
technical file: model, code, serial number, maximum and minimum OT, OP, year of manufacture, EC label,
manufacturer’s address, refrigerant and weight, electrical parameters, thermo‐dy namic and acoustic
performances.
4.3Availableaccessories
Name PACNET Winteringcover Remotecontrolunit Technicalroomkit
Representation
4.4Recycling
Thissymbolmeansthatyourdevicemustnotbethrowninthebin.Thedevicemustbecollectedbya
selective system in view of re‐use, recycling or similar. Any substances it may contain which are
potentiallydangeroustotheenvironmentshallbeeliminatedorneutralised .
Requestinformationonrecyclingproceduresfromyourretailer.
5.Troubleshooting
5.1Displayoftheregulator
Display Designation Cause Solution Reset
Protectionof
heatexchanger
incoldmode
TemperatureofST4
sensortoolow
Waitforthesurrounding
temperaturetobe come
warmer
Automatic
High
temperature
defectforthe
evaporatorin
"cooling"mode
TemperatureprobeST3
above60°Cor
evaporatorscaledup
Cleantheevaporator,ifthe
defectpersists,contactan
approvedtechnician
Automaticif
temperature
probeST3is
below45°C
Phaseorder
defect(onlyon
three‐phased
models)
1.wiringincorrecton
thesupplyterminal
boardofthedevice,
2.modificationofphase
orderbyelectrical
supplier,
3.temporaryfailureof
oneorseveralphases
1.reversethephasesonthe
supplyterminalboard
(withoutpowertothedevice)
2,3,4.con
tactyourelec
tricity
providertofindoutif
modificationshavebeenmade
toyourequipment.
Switchthe
power
supplyoffor
press
