H03609‐00.B1.EN–2012/01
4
electriccablesshallbefixed,
acceptabletoleranceoftensionvariation:±6%(whileworking),
thestuffingboxmustbeusedforallelectricalconnections.
2.4.2Connections
theelectricalsupplycable mustnotbeexposedtoelementsthataresharp,hotorrepresentacrushhazard,
checkthatallcablesaresecureandallterminalconnectionsarecorrect.
Factoryconfiguration: all 3‐6‐9 kW heaters have a power terminal strip equipped with clamps for an
electrical connection to the single‐phase power supply 230V‐50Hz‐. For connection to the three‐phase
powersupply400V‐50Hz‐plusneutral,removethesecla mps.
Looseterminalsmaycausethesupplyterminalboardtooverheat,andwillvoidthewarranty.
Thedevicemustbeconnectedtoanearthelectrode.
Riskofelectric shockinsidethedevice.
Thedevicemustonlybeconnectedbyaqualifiedandexperiencedtechnician.
Ifthepowercableisdamaged,itmustbereplacedbyaqualifiedtechnician.
Single‐phase Three‐phase
2.4.3Cablecross‐sections
•supply cable cross‐section: cables with a maximum length of 20 metres (calculation base: 5A/mm²), must be
checkedandadapteddependingoninstallationconditions.
RE/LE Voltage
Currentconsumption Cablesection Electricalprotection
A mm² A
3
230V/1N/50Hz 14 3x4 3G4 16
400V/3N/50Hz 5 5x2.5 5G2.5 10
6
230V/1N/50Hz 27 3x6 3G6 32
400V/3N/50Hz 9 5x2.5 5G2.5 16
9
230V/1N/50Hz 40 3x10 3G10 50
400V/3N/50Hz 13 5x4 5G4 16
12 400V/3N/50Hz 18 5x4 5G4 20
3.Use
3.1Startingthedevice
switchonthefiltrationpump,
checkthedegassingand watercirculationintheheater,
engagetheprotective30mAdifferentialcircuitbreakerassociatedwiththeheater,
settheswitchtothe“on”position,
adjustthecontrolthermostattothedesiredtemperature.
Marks*to6:*=16°C;1=20°C;2= 24°C;3=28°C;4=32°C;5=36°C;6=40°C
theindicatorofheatingoforangecolorindicatesthatthedeviceisheatingthebasin
3.2Checkstobecarriedoutafteroperatingforafewmoments
Checkthattheheaterstopsheatingwhen:
decreasing the required temperature on the control display (if the poolwaterilbelow 16 °C, the heater will
alwaysbeoperating,althoughitissetto“*”),
filtrationisswitchedoff.
Heaterterminalstrip
Shunt
Powercable
30mAdifferential
circuitbreaker
Phase
Neutral
Earth
