H03609‐00.B1.EN–2012/01

3

2.Installation



2.1Selectinganinstallationsite





Itisimperativethattheappliancebeinstalledclosetothepoolfilter.

Inanycase,thedevicemustNOTbeheldbythefiltrationpipes.



 Installtheapplianceatthefiltersystemlowpointsothatitsbodyispermanentlyfilledwithwaterbyretention, 

 Theappliancemustbeinstalledverticallyandonalevelinordertoallowtheevacuationofwaterthroughthe

holeintheelectricbox(see"Description"§intheap

pendix),

 Thesuppliedsupportcanbeusedtomounttheheateronthewall,

 For indoor installation, the appliance must be installed in a technical room ventilated,  dry and without stored

pooltreatmentproducts,

 Foroutdoorinstallation,theappliancemustbeinstalledataminimumdistancefromtheendofthepoolsoas

toavoidexpo

suretowatersplashes.Theappropriatedistanceshouldbedefinedwithreferencetothenational

electricalstandardsthatapplyinthecountryofinsta llation(inFrance:3.5meters).



2.2Installingthedevice



 Theappliancemustbeinstalledintheverticalposition,

 fixthesupporttothewallwithinsertsandthesuppliedscrews

(seethecent repoint sizes §"Sizes"intheappendix),

 usingascrewdriver,opentheblackplasticholdstraps, 

 placetheheaterbodyonthesupport,

 closeth

estraps,

 checkthattheapplianceiscorrectlyfixedtotheside.



2.3Hydraulicconnections





Observethehydraulicconnectiondirection.



TheconnectionshallcompriseaPVCrigidpipe:

- directlyiftheflowrateislessthan22m³/hour,

- fromaby‐passifthewaterflowrateisgreaterthan22m³/h,

- itisrecommendedtouseaby‐passasthismakesmaintenanceoftheappliancesimpler,

- ontheswimming poolfiltrationcir

cuit,afterthefilterandbeforeanywatertreatmentunit.

Checkthetighteningofthehydraulicconnections,andforleaks.







RE/LE

Hydrauliccircuitpressure

Connections

Minimumwater

flowrate

Maximum

waterflowrate

test service

3‐6‐9‐12 4bars 2bars

Ø50inlet

Ø63outlet

5m³/h 22m³/h



2.4Electricalconnections



2.4.1Voltageandprotection



 theelectricalsupplytotheheatermustpassviaaprotectionanddisconnectiondevice(notsupplied)complying

withthestandardsandregulationsinforceinthecountry,

 electricalprotection:30mAdifferentialtripswitch(circuit‐breakerorswitch)dedicated.













V1‐V2‐V3:by‐passvalves

RE/Lequipped

pump

filter

watertreatmentunit
