H03846‐00.A1.EN–2012/10 4
Ventilation,renewalofair:
- privatepools:highlyrecommended,
- publicpools:compulsory.
Theaircanberenewedby:
- asimplemechanicalventilationunit,
- awallorroofextractorwithfreshairintakes,
Thisventilationensuresthehygienicrenewalofair,theremovalofanychloraminespresentintheair,
andtheeliminationofexcessivelyhotair,whilstcontributingtothedehumidificationoftheroom.
FollowingFrenchnormNFC15‐100,theapplianceshouldbeinstalled:
- Outside of area 1(more than 2 metres from the edge of the pool) provided it is out of reach of
potentialsplashesandprotectedbyadedicated30mAfuse,
- Outside ofarea2 (more than3.5metresfromthe edgeofthe pool) ifthe above conditions arenot
satisfied.
2.2Connectiontosurroundingair(onlyonCAE)
Leavesufficientspacetoinstallablowerplenum(unitdistributingairtotheblowingsystem)ontopoftheunitin
ordertoorienttheairflow,ifpossibletowardsthebaywindowsopeningontheexterior.
2.3Connectionthroughadividingwall(onlyonCAE)
Plan610x410mmspacesinthewallbetweenthetechnicalroomandthepoolhall.
Inthewallonthepoolside,sealthestandardgrateframeonthebottom(without anyequipotentialconnection
to the sound trap) and the double deflector grate on the top (without any equipotential conne
ction with the
blowerelbow).
Onthetechnicalroomsideconnectthemadetomeasuremetalwork(soundtrap,blowerelbow)tothesystem
andfitafoamjoint
forwatertightnessandtoblockanyvibrations.
*minimumdistance
CAE508‐510‐513
extractorgrate
doubledeflectorgrate
HygroControl
freshairintake
airrenewalsystem(see§2.1)
condensationdrainage
airflowbox
suction
blowing
Pool
